US$14,000.00-24,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Type
Worktable Milling Machine
Milling Cutter Type
Vertical Milling Cutter
Automatic Grade
Automatic
Certification
GS, CE, RoHS, ISO 9001
Control system
GSK980MDI or SYNTECH
Auto tool changer
Umbrella type
Specification
1900*1650*2650
Production Capacity
2000 sets/Year
Product Description
Machine Features/Our Advantanges Equipped with BT40 spindle. 12 tools Automatic Tool Changer with GSK CNC Controller. All 3-axis equipped with linear guideway. Reliablie casting structure to provide sufficient rigidity for production. Economical selection with productive efficiency, excellent quality and precise accuracy to satisfy most of daily production. 1 year warranty and permanent after-sale service Technical Specification
| HMX40C |
| Items | Unit | Measurement |
| X-Axis Servo Travel | mm | 900 |
| Y-Axis Servo Travel | mm | 340 |
| Z-Axis Servo Travel | mm | 400 |
| X/Y/Z Axis Rapid Feed | mm/min | 10,000 |
| Table Size(L×W) | mm | 1470×320 |
| Max. Working Load | kg | 200 |
| T-slots (Width×No.) | mm-No. | 16-#3 |
| Max.Spindle Speed | rpm | 6000 |
| Spindle Drive Type | | Belt |
| Spindle Taper | | BT40 |
| Tool Capacity | pcs | 12 |
| Max.Tool Weight | kg | 6 |
| Tool Changer Type | | Umberlla |
| Spindle Main Motor | kW | 3.7 |
| X/Y/Z Servo Feed Motor | kW | 6/6/14.5 |
| Machine Size | mm | 1900×1650×2650 |
| Machine Weight | kg | 1,800 |
| Positioning Precision | mm | ±0.01/300 |
| Repeat Positioning Precision | mm | ±0.02 |
| Control System | | GSK980MDi |
| Standard Accessories: | - Automatic Lubrication System
- Coolant System
- Working Lamp
- Tool Box
- RS-232 & USB Interface
- Automatic Tool Changer
- Unclamping Cylinder
- Sheet Metal Protective Shield |
|
|
Pictures for reference only:
>>
