UL Certificated 600V 12-2 14/2 2/0 12/2 Aluminum/Copper Core Teck 90 Teck90 Aia Interlocked Armoured Electric Cable

Product Description

Product Description
TECK 90 aluminium interlocked armour electric power cable
APPLICATIONS:
Suitable for use in ventilated, non-ventilated and ladder cable trays, direct earth burial or raceways, and for exposed or concealed wiring in wet, damp or dry locationsSuitable for use in wet or dry locations when installed in accordance with the NEC
Suitable for use in all hazardous locations when used with certified HL cable glands.
STANDARDS:
UL 1581
IEEE 1202
OSHA Acceptable
Hazardous location rating - HL
CABLE CONSTRUCTION:

Construction
Category Conductor Description	Aluminium/Copper Conductor Class B In sizes 8 AWG to 1000 kcmil
Category Insulation Description	Cross-linked Polyethylene (XLPE) Type RW90
Category Assembly Description	Cabled in concentric layers with grounding wire, interstices are filled with suitable nonhygroscopic fillers, as required A binder tape of synthetic material assembles the core in an essentially round configuration, as required
Ground	The ground consists of one uninsulated stranded bare copper conductor
Inner Jacket	Black, lead-free, flame retardant, moisture and sunlight resistant Polyvinyl Chloride (PVC)
Armor	Aluminum interlocked armor
Outer Jacket	Black, lead-free, flame retardant, moisture and sunlight resistant Polyvinyl Chloride (PVC)

CABLE PARAMETERS:

AWG/MCM	Conductors	Ground Gauge	Insulation Thickness	Nominal OD over Armor	Outside Diameter Inches	Material Weight (Lbs./M')	Material Weight (KG/KM)
8	3	10	0.045	0.86	0.94	482	717
8	4	10	0.045	0.92	1	570	848
6	3	8	0.06	1.03	1.13	695	1034
6	4	8	0.06	1.04	1.25	883	1314
4	3	8	0.06	1.16	1.25	950	1413
4	4	8	0.06	1.18	1.35	1161	1727
2	3	6	0.06	1.28	1.37	1300	1934
2	4	6	0.06	1.45	1.46	1568	2333
1/0	3	6	0.08	1.56	1.68	1871	2784
2/0	3	6	0.08	1.65	1.77	2177	3239
3/0	3	4	0.08	1.75	1.87	2619	3897
4/0	3	4	0.08	1.86	1.98	3176	4726
350	3	3	0.09	2.26	2.4	4989	7424
500	3	3	0.09	2.52	2.66	6706	9979

For other sizes,pls contact us! Company Profile
Certifications
Quality Inspection
Cooperative Customers
Packaging & Shipping
FAQ
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

---
