Chain /Hydraulic Brinell Hardness Tester Bh-3000c

Product Description

Chain /Hydraulic Brinell Hardness Tester BH-3000C
Basic Info
BH-3000C portable Brinell hardness tester has the same structure as King Brinell hardness tester. The test condition is applying 3000kg test force on a 10mm carbide indenter.
It can result in permanent indentations for re-inspection. The test condition meets with ISO 6506 and ASTM E110.
Features
On-site Testing
It is a portable instrument suitable to use in the plant. It is easy to operate and convenient to carry. So it can be used to easy test large work pieces in any direction on site.
Permanent Indentation
With 3000kg test force and 10mm ball indenter, the indentation can accurately reflect the true harness of cast iron, cast steel, forge piece, and other materials with coarse grain. The permanent indentation can be reinspected at any time after testing.
Real Result
BH-3000C has the same principle as the bench type Brinell hardness tester. So the result is totally different from the lossy conversion value of other portable hardness testers (eg. Rebound type hardness tester).
Wide Testing Range
BH-3000C has various test forces and two different ball indenters in order to test different metals.
High Cost Performance
The parts machining workmanship and assembling accuracy of BH-3000C is much better than King Brinell hardness tester. It has an improved jacking system free from gear jamming, while the price is lower than King Brinell Hardness Tester. So BH-3000C Brinell hardness tester has a higher cost performance.
Technical specifications

Test Force	3000kg (500kg, 750kg, 1000kg, and 1500kg optional)
Indenter	Ф10mm carbide ball indenter (Ф 5mm optional)
Testing Range	100-650HBW (expendable to 28- 650HBW)
Max. Specimen Height	320mm
Max. depth of specimen	100mm
Accuracy	coform with ISO 6506
Repeatability	comform with ISO 6506
Net Weight	13.8kg

Standard accesory

Main unit	1PC	20X reading microscope (with LED light)	1PC	Dome anvil	1PC
Hardness Block HBW/3000/10 (150-250)	1PC	V anvil	1PC	Ф10mm spare carbide ball indenter	1PC
Hardness block HBW/750/05 (75-150)	1PC	Flat anvil	1PC	Hexagon Wrench	1PC

Exhibition
Our Partner
Company Profile
SHENZHEN PRIDE INSTRUMENT INC.,Founded in 2001,our company specializes in development,manufacturing,markting and sales of measurement instrucments and equipment.We have been operating on the four management concepts:Quality,Speed,Innovation and Responsibility.SHENZHEN PRIDE INSTRUMENT INC. has been devoted to innovations R&D uncreasingly and has accumulated years of experiences in design and manufacturing.Our products sold all over the world,our friends are all over the world.Our company introduced the ISO9001 Iternational quality assurance operation system,our products approved by CE,ROHS.
OUR PRODUCTSLINES:
1.MEASURING TOOLS
2.HARDNESS TESTING
3.METALLOGRAPHY
4.FORCE & TORQUE
5.NDT INSPECTION
6.ELECTRICAL INSTRUMENT
7.OPTICAL INSTRUMENTS
8.MATERIAL TESTING
9.PAINT TESTING
FAQ
Q1. Can I have a sample order ?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 20-45days for order quantity more than 1000.
Q3. Do you have any MOQ limit for order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

---
