GBHW-1200 Fully Automatic Bridge Type Edge Cutting Machine for Granite and Marble

Product Description

Introduction:
1, Controlled by PLC, operated expediently,accurately and stably
2,The support guide way adopts the imported linear guide way to make sure high precision and long life.
3, The main parts and components of the machine (such as frequency converter, magnetic rule, laser reticule apparatus.) are all of imported good-quality materials, thus ensuring high precision, stable performance, good adaptability as well as high reliability of the whole machine.
Common station: concrete foundation, table rotate 90 degree; We can make to order: steel structure, table rotate360 degree.

Name	Unit	GBHW-1200	GBHW-1400
Blade diameter	mm	1200	1400
Main motor	kw	22	30
Max.cutting size	mm	3200x2000	3200x2000
Worktable rotating		90 or 360	90 or 360
Blade up and down stroke	mm	700	700
Weight	kg	6500	7000

NOTE:Prodiling function can be ordered
Main Features
1) Machine with competitive price and high quality ,easy in installation and maintenance.
2) Adopting advanced world famous brand components in electric parts .
3) Guarantee for one year.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
FAQ
1. Do you have more stone machines?
Yes, we can produce all series of stone processing machines with competitive price and high quality.
2. Where is your factory?
Our factory locates in Xiangbei Industry Zone,Xiang'an,Xiamen,Fujian.
3. Do you have agent?
We don't have agent as we all sell directly to our customer, in this way, the customer can get lowest cost.
4. How much is this machine?
Please tell me your stone is granite or marble, the size, your destination port, so that I can quote you best price.
5. How long can I get my product?
Normally it takes 30 days to produce our products

---
