ram turret milling machine X6330 5H taiwan turret milling machine price

Product Description

Product Description
Turret Milling Machine X6330(5H) Main Features:
1. We're professional X6330 small turret milling machine suppliers in China, specialized in providing high quality products with low price.
2. Universal milling machine having a table fitted with all motions and a dividing head with change gears so that it can perform any type of milling operation.
3. Rectangular guideway on Y and Z axis makes the machine stable and rigid.
4. The guideway on saddle is lined with TF wearable material.
5. Fixed structure is used to connect the mill head without addapter, which makes the cut intensity well.
6. DRO is optional.
7. It is with Taiwan milling turret head.
8. Rectangular guideway on Y and Z axis makes the machine stable and rigid. 9. The guideway on saddle is lined with TF wearable material. 10. Fixed structure is used to connect the mill head without addapter, which makes the cut intensity well.

Specificaiton	X6330(5H)
Table size(L×W)	1370×305mm
T-slotes (NxWxD)	3/16/85mm
Table travel (X/Y/Z)	850×400×450mm
Distance between spindle nose and table surface	0-460mm
Spindle speed	66-4540rpm
Main motor power	5HP
Spindle taper	NT40
Travel of spindle sleeve	127mm
Ram travel	500mm
Feed of spindle sleeve	0.03/0.08/0.15inch/r
Milling head rotation	swivel:45° tilt:90°
Overall size (L×W×H)	1750×1650×2150mm
N.w	1350kg

Company Profile

FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4: What's the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes, we have professional engineers and designers. We can provide OEM services.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.

---
