0.6/1kv XLPE/PVC Insulated Copper/Aluminum Factory Price Power Cable Electrical Wire ABC Cable

Product Description

Product Description Aerial Bundled Cable
Low-voltage ABC cable, designed for overhead power lines and room entrance wires with a rated AC pressure of 1kv and below. It has less installation, maintenance, and operating costs, which can achieve greater economic loss and provide higher security and reliability.
Specification
Duplex Service Drop-Aluminum Conductor

Code	Phase Conductor			Bare Neutral Messenger			Weight Per		Rating(Amps)
Name							1000 ft(lbs)
	Size	Strand	Insulation	Size	*Strand	Breaking	XLP	POLY	XLP	POLY
	AWG		thickness	AWG		strength
			(MLS)			(lbs)
AAC
Pekingese	6	solid	45	6	7/w	563	63.5	61.7	70	70
Collie	6	7/w	45	6	7/w	563	66.8	63.1	70	70
Dachshund	4	solid	45	4	7/w	881	95.5	93.4	90	90
Spaniel	4	7/w	45	4	7/w	881	101	95.4	90	90
Doberman	2	7/w	45	2	7/w	1,350	153	145.7	120	120
Malemute	1/0	19/w	60	1/0	7/w	1,990	243	234.2	160	160
ACSR NEUTRAL-MESSENGER
Setter	6	solid	45	6	'6/1	1.19	75	73.2	70	70
Shepherd	6	7/w	45	6	'6/2	1.19	78.3	74.6	70	70
Eskimo	4	solid	45	4	'6/3	1.86	114	111.6	90	90
Terrier	4	7/w	45	4	'6/4	1.86	119	113.6	90	90
Chow	2	7/w	45	2	'6/5	2.85	182	174.7	120	120
Bull	1/0	19/w	60	1/0	'6/6	4.38	289	280.3	160	160
6201 ALLOY NEUTRAL-MESSENGER
Chihuahua	6	solid	45	6	7/w	1,110	67.6	65.8	70	70
Vizsla	6	7/w	45	6	7/w	1,110	70.9	67.2	70	70
Harrier	4	solid	45	4	7/w	1,760	102	99.9	90	90
Whippet	4	7/w	45	4	7/w	1,760	107	101.9	90	90
Schnauzer	2	7/w	45	2	7/w	2,800	163	156.2	120	120
Heeler	1/0	19/w	60	1/0	7/w	4,460	259	250.8	160	160

Triplex Service Drop-Aluminum Conductor

Code	Phase Conductor				Bare Neutral Messenger			Weight Per		Ampacity (Amps)
Name								1000 ft(lbs)
	Size		Stranding	Insulation	Size	Stranding	Breaking	XLP	POLY	XLP	POLY
	AWG			thickness	AWG		strength
				(MLS)			(lbs)
6201 ALLOY NEUTRAL-MESSENGER
Minex		6	solid	45	6	7	1,110	106.6	102.9	85	70
Hippa		6	7/w	45	6	7	1,110	113.2	105.7	85	70
Prawn		4	solid	45	4	7	1,760	158.4	154.1	115	90
Barnacles		4	7/w	45	4	7	1,760	168.3	158.2	115	90
Shrimp		2	7/w	45	2	7	2,800	253.7	239.7	150	120
Gammarus		1/0	7/w	60	1/0	7	4,460	411.7	386	205	160
Leda		1/0	19/w	60	1/0	7	4,460	402.7	386	205	160
Dungenese		2/0	7/w	60	2/0	7	5,390	506.8	476.3	235	185
Cyclops		2/0	19/w	60	2/0	7	5,390	495.3	476.3	235	185
Flustra		3/0	19/w	60	3/0	7	6,790	611.4	589.1	275	215
Lepas		4/0	19/w	60	4/0	7	8,560	757.1	730.5	315	245
6201 ALLOY REDUCED NEUTRAL-MESSENGER
Artemia		4	solid	45	6	7	1,110	141.4	137.1	115	90
Crab		4	7/w	45	6	7	1,110	151.3	141.2	115	90
Solaster		2	7/w	45	4	7	1,760	226.6	212.6	150	120
Sandcrab		1/0	7/w	60	2	7	2,800	368.8	343.1	205	160
Echinus		1/0	19/w	60	2	7	2,800	358.8	343.1	205	160
Crayfish		2/0	7/w	60	1	7	3,530	452.6	422.5	235	185
Sipho		2/0	19/w	60	1	7	3,530	441	422.5	235	185
Fulgar		3/0	19/w	60	1/0	7	4,460	543.4	521.1	275	215
Arca		4/0	19/w	60	2/0	7	5,390	671.2	644.6	315	245
AAC NEUTRAL-MESSENGER
Haiotis		6	solid	45	6	7	563	102.5	98.8	85	70
Patella		6	7/w	45	6	7	563	109.1	101.6	85	70
Fusus		4	solid	45	4	7	881	151.9	147.6	115	90
Oyster		4	7/w	45	4	7	881	161.8	151.7	115	90
Clam		2	7/w	45	2	7	1,350	243.2	229.2	150	120
Murex		1/0	7/w	60	1/0	7	1,990	395.1	369.4	205	160
Purpura		1/0	19/w	60	1/0	7	1,990	386.1	369.4	205	160
Nassa		2/0	7/w	60	2/0	7	2,510	485.8	455.3	235	185
Melita		3/0	19/w	60	3/0	19	3,310	585.2	562.9	275	215
Portunus		4/0	19/w	60	4/0	19	4,020	723.9	697.3	315	245
Nannynose		336.4	19/w	80	336	19	6,146	1160	1118	420	325
WITH FULL SIZE ACSR MESSENGER
Paludina		6	solid	45	6	'6/1	1,190	114	113	85	70
Voluta		6	7/w	45	6	'6/1	1,190	120	113	85	70
Whelk		4	solid	45	4	'6/1	1,860	169	165	115	90
Periwinkle		4	7/w	45	4	'6/1	1,860	176	172	115	90
Conch		2	7/w	45	2	'6/1	2,850	267	261	150	120
Neritina		1/0	7/w	60	1/0	'6/1	4,380	530	419	205	160
Cenia		1/0	19/w	60	1/0	'6/1	4,380	426	416	205	160
Runcina		2/0	7/w	60	2/0	'6/1	5,310	530	519	235	185
Triton		2/0	19/w	60	2/0	'6/1	5,310	526	514	235	185
Cherrystone		3/0	7/w	60	3/0	'6/1	6,620	656	643	250	200
Mursia		3/0	19/w	60	3/0	'6/1	6,620	650	638	250	200
Razor		4/0	7/w	60	4/0	'6/1	8,350	814	799	315	245
Zuzara		4/0	19/w	60	4/0	'6/1	8,350	805	792	315	245
Limpet		336.4	19/w	80	336	'6/1	8,680	1209	1167	420	325
WITH ACSR REDUCED SIZE MESSENGER
Scallop		4	Solid	45	6	'6/1	1,190	148	144	115	90
Strombus		4	7/w	45	6	'6/1	1,190	158	148	115	90
Cockle		2	7/ w	45	4	'6/1	1,860	233	227	150	120
Janthina		1/0	7/ w	60	2	'6/1	2,850	376	365	205	160
Ranella		1/0	19/ w	60	2	'6/1	2,850	372	362	205	160

Quadruplex Service Drop-Aluminum Conductor

Code	Phase Conductor			Bare Neutral Messenger			Weight Per		Rating(Amps)
Name							1000 ft(lbs)
	Size	Strand	Insulation	Size	Strand	Breaking	XLP	POLY	XLP	POLY
	AWG		thickness	AWG		strength
			(MLS)			(lbs)
AAC NEUTRAL-MESSENGER
Clydesdale	4	Solid	45	4	7	881	208	201.8	100	80
Pinto	4	7/w	45	4	7	881	223	207.9	100	80
Mustang	2	7/w	45	2	7	1,350	333	312.6	135	105
Criollo	1/0	19/w	60	1/0	7	1,990	529	504.5	180	140
Percheron	2/0	19/w	60	2/0	7	2,510	649	620.5	205	160
Hanoverian	3/0	19/w	60	3/0	19	3,310	799	765.6	235	185
Oldenburg	4/0	19/w	60	4/0	19	4,020	986	946.7	275	210
Lippizaner	336.4	19/w	80	336.4	19	6,146	1,546	1,519.20	370	280
ACSR NEUTRAL-MESSNGER
Morochuca	6	Solid	45	6	'6/1	1,190	152	147.4	75	60
Chola	6	7/w	45	6	'6/1	1,190	162	151.7	75	60
Morgan	4	Solid	45	4	'6/1	1,860	226	220	100	80
Hackney	4	7/w	45	4	'6/1	1,860	241	226.1	100	80
Palomino	2	7/w	45	2	'6/1	2,850	362	342.6	135	105
Costena	1/0	19/w	60	1/0	'6/1	4,380	575	550.6	180	140
Grullo	2/0	19/w	60	2/0	'6/1	5,310	707	678.7	205	160
Suffolk	3/0	19/w	60	3/0	'6/1	6,620	872	838.9	235	185
Appaloosa	4/0	19/w	60	4/0	'6/1	8,350	1079	1039.2	275	210
Bronco	336.4	19/w	80	336.4	'18/1	8,580	1613	1568.2	370	280
Gelding	336.4	19/w	80	4/0	'6/1	8,350	1548	1494.3	370	280
6201 ALLOY NEUTRAL-MESSENGER
Bay	6	Solid	45	6	7	1,110	145	140	75	60
French Coach	6	7/w	45	6	7	1,110	155	144.3	75	60
German Coach	4	Solid	45	4	7	1,760	214	208.3	100	80
Arabian	4	7/w	45	4	7	1,760	229	214.4	100	80
Belgian	2	7/w	45	2	7	2,800	344	323.1	135	105
Shetland	1/0	19/w	60	1/0	7	4,460	546	521.1	180	140
Thoroughbred	2/0	19/w	60	2/0	7	5,390	670	641.5	205	160
Trotter	3/0	19/w	60	3/0	7	6,790	825	791.8	235	185
Walking	4/0	19/w	60	4/0	7	8,560	1019	979.7	275	210

6201 ALLOY NEUTRAL-MESSENGER
Code Name	Phase Conductor			Bare Neutral Messenger			Weight Per 1000ft(lbs)		Rating(Amps)
	Size AWG	Strand	Insulation Thickness(mls)	Size AWG	Strand	Breaking Strength(lbs)	XLPE	Poly	XLPE	Poly
Bay	6	Solid	45	6	7	1,110	145	140.0	75	60
French Coach	6	7/w	45	6	7	1,110	155	144.3	75	60
German Coach	4	Solid	45	4	7	1,760	214	208.3	100	80
Arabian	4	7/w	45	4	7	1,760	229	214.4	100	80
Belgian	2	7/w	45	2	7	2,800	344	323.1	135	105
Shetland	1/0	19/w	60	1/0	7	4,460	546	521.1	180	140
Thoroughbred	2/0	19/w	60	2/0	7	5,390	670	641.5	205	160
Trotter	3/0	19/w	60	3/0	7	6,790	825	791.8	235	185
Walking	4/0	19/w	60	4/0	7	8,560	1,019	979.7	275	210

Packaging & Shipping
Electric Wire
PVC insulated wires belong to the series of laying electric wires, which are mainly suitable for placing at the fixed places. It is widely used as connectors of drive, lighting, electronic equipment, instrument and telecommunication equipmentwith rated voltage 450/750V (U0/U) or below. Parts of the plastic wires are used at the equipment with AC rated voltage 300/300V or below.

Model	Name
BV	Copper Core PVC Insulation Wire
BLV	Aluminum Core PVC Insulation Wire
BVR	Copper Core PVC Insulation Flexible Wire
BVV	Copper Core PVC Insulation PVC Sheath Round Wire
BVVB	Copper Core PVC Insulation PVC Sheath Flat Wire
BLVVB	Aluminum Core PVC Insulation PVC Sheath Flat Wire
BV-90	Copper Core Heat-resistance 105oC PVC Insulation

Specification
BV 450/750V

Nominal Section(mm²)	No./Dia. of Core (mm)	Max O.D(mm)	Reference Weight (kg/km)	Conductor Resistance at 20oC≤(Ω/km)
0.5	1/0.80	2.4	8.5	36.0
0.75(A)	1/0.97	2.6	11.1	24.5
0.75(B)	7/0.37	2.8	12.0	24.5
1.0(A)	1/1.13	2.8	13.9	18.1
1.0(B)	7/0.43	3.0	15.0	18.1

BV BLV(BV-90)450/750V

Nominal Section(mm²)	No/Dia.of Core(mm)	Max O.D (mm)	Reference Weight(kg/km)		Conductor Resistance at 20oC≤(Ω/km)
			Copper	Aluminum	Aluminum	Copper
1.5(A)	1/1.38	3.3	20.3	/	/	12.1
1.5(B)	7/0.52	3.5	21.6	/	/	12.1
2.5(A)	1/1.78	3.9	31.6	17	11.8	7.41
2.5(B)	7/0.68	4.2	34.8	/	/	7.41
4(A)	1/2.55	4.4	47.1	22	7.39	4.61
4(B)	7/0.85	4.8	50.3	/	/	/
6(A)	7/0.85	4.8	50.3	29	4.91	3.08
6(B)	7/1.04	5.4	71.2	/	/	3.08
10	7/1.35	7.0	119	62	3.08	1.83
16	7/1.70	8.0	179	78	1.91	1.15
25	27/2.04	10.0	281	118	1.20	0.727
35	27/2.52	11.5	381	156	0.868	0.524
50	19/1.78	13.0	521	215	0.641	0.387
70	19/2.14	15.0	734	282	0.443	0.268
95	19/2.52	17.5	962	385	0.320	0.193
120	37/2.03	19.0	1180	431	0.253	0.153
150	37/2.25	21.0	1470	539	0.206	0.124
185	37/2.52	23.5	1810	666	0.164	0.0991
240	61/2.25	26.5	2350	857	0.125	0.0754
300	61/2.52	29.5	2930	1070	0.100	0.0601
400	61/2.85	33.0	3870	1390	0.0778	0.0470

BVVB, BLVVB 300/500V

Nominal Section	Structure of Cores Core x No./Dia	Max Outer Dia (mm)		Reference Weight(kg/km)		Conductor Resistance at 20oC≤(Ω/km)
(mm²)	(mm)	Aluminum	Copper	Copper	Aluminum	Copper	Aluminum
2×0.75	2×1/0.97	/	4.6×7.0	43.7	24.5	/	/
2×1.0	2×1/1.13	/	4.8×7.4	51.0	18.1	/	/
2×1.5	2×1/1.38	/	5.4×8.4	65.9	12.1	/	/
2×2.5	2×1/1.78	6.2×9.8	6.2×9.8	95.7	64.9	7.41	11.8
2×4	2×7/0.85	6.8×11.0	7.2×11.5	146.0	80.7	4.61	7.39
2×6	2×7/1.04	7.4×12.0	8.0×13.0	200.0	104	3.08	4.91
2×10	2×7/1.35	9.6×16.0	9.6×16.0	323.0	177	1.83	3.08
3×0.75	3×1/0.97	/	4.6×9.4	62.6	/	24.5	/
3×1.0	3×1/1.13	/	4.8×9.8	74.3	/	18.10	/
3×1.5	3×1/1.38	/	5.4×11.5	95.6	/	12.10	/
3×2.5	3×1/1.78	6.2×13.5	6.2×13.5	140	93.9	7.41	11.8
3×4	3×7/0.85	7.0×15.0	7.4×16.5	220	123	7.41	7.39
3×6	3×7/1.04	7.4×17.0	8.0×18.0	295	153	4.61	4.91
3×10	3×7/0.35	9.6×22.5	9.6×22.5	485	261	1.83	3.08

BVV 450/750V

Nominal Section(mm²)	Structure of Cores Core x No./Dia (mm)	Max Outer Dia(mm)	Reference Weight(kg/km)
1×0.75	1×1/0.97	4.3	23
1×1.0	1×1/1.13	4.5	26.4
1×1.5(A)	1×1/1.38	4.9	34.6
1×1.5(B)	1×7/0.52	5.2	36.5
1×2.5(A)	1×1/1.78	5.8	46.4
1×4(A)	1×1/2.25	6.4	65.9
1×4(B)	1×7/0.85	6.8	73.7
1×6(A)	1×1/2.76	7.0	91.6
1×10	1×7/1.35	8.8	152.0
2×1.5(A)	2×1/1.38	9.8	109
2×1.5(B)	2×7/0.52	10.5	123
2×2.5(A)	2×1/1.78	11.5	157
2×2.5(B)	2×7/0.68	12.0	172
2×4(A)	2×1/2.25	12.5	205
2×4(B)	2×7/0.85	13.0	222
2×6(A)	2×1/2.76	13.5	265
2×6(B)	2×7/1.04	14.5	286
2×10	2×7/1.35	18.0	471
3×1.5(A)	3×1/1.38	10.5	136
3×1.5(B)	3×7/0.52	11.0	146
3×2.5(A)	3×1/1.78	12.0	190
3×2.5(B)	3×7/0.68	12.5	207
3×4(A)	3×1/2.25	13.0	252
3×4(B)	3×7/0.85	14.0	272
3×6(A)	3×1/2.76	14.5	344
3×10	3×7/1.35	19.0	574
4×1.5(A)	4×1/1.38	11.5	164
4×1.5(B)	4×7/0.52	12.0	174
4×2.5(B)	4×7/0.68	13.5	252
4×4(A)	4×1/2.25	14.5	321
4×4(B)	4×7/0.85	15.5	346
4×6(A)	4×1/2.76	14.5	470
4×6(B)	4×7/1.04	15.5	439
5×1.5(A)	5×1/1.38	12.0	192
5×1.5(B)	5×7/0.52	12.5	205
5×2.5(A)	5×1/1.78	14.0	272
5×2.5(B)	5×7/0.68	14.5	292
5×4(A)	5×1/2.25	16.0	379
5×4(B)	5×7/0.85	17.0	418
5×6(A)	5×1/2.76	17.5	518
5×6(B)	5×7/1.04	18.5	550

Packaging & Shipping
Bare conductors
Bare conductors are used as overhead power lines, transmission lines, and distribution lines. Different conductor materials are suitable for different span lengths and the ability to withstand breaking strength. All aluminum conductors consist of one or more bundles of aluminum wire, depending on the specific application environment of the product. Due to the natural corrosion resistance of the all-aluminum structure, it is also popular in coastal areas. Compared with AAC and ACSR, AAAC has better strength and weight, better electrical properties, better vertical tensile properties, and better corrosion resistance. These characteristics make AAAC widely recognized and loved by more people in power distribution and medium and high voltage transmission lines.
Specification

Code Name	Size (KCM)	Strand	Approx.EC Cond with Equivalent Resistance	Stranding	Diameter(in)		Cross Sectional Area (Sq in)	Weight per 1000ft (lbs)	Rated Strength (lbs)	Resistance Ohms/1000ft (lbs)
					Individual Wires	Complete Cable				DC @ 20ºC	AC@ 75ºC
Akron	30.58	7/w	6	6/1	.0661	.198	.0240	28.7	1,110	.659	.785
Alton	48.69	7/w	4	6/1	.0834	.250	.0382	45.7	1,760	.414	.493
Ames	77.47	7/w	2	6/1	.1052	.316	.0608	72.7	2,800	.260	.310
Azusa	123.3	7/w	1/0	6/1	.1327	.398	.0968	115.7	4,460	.163	.195
Anaheim	155.4	7/w	2/0	6/1	.1490	.447	.1221	145.9	5,390	.130	.154
Amherst	195.7	7/w	3/0	6/1	.1672	.502	.1537	183.7	6,790	.103	.123
Alliance	246.9	7/w	4/0	6/1	.1878	.563	.1939	231.8	8,560	.0816	.0973
Butte	312.8	19/w	266.8	26/7	.1283	.642	.2456	293.6	11,000	.0644	.0769
Canton	394.5	19/w	336.4	26/7	.1441	.721	.3098	370.3	13,300	.0511	.0610
Cairo	465.4	19/w	397.5	26/7	.1565	.783	.3655	436.9	15,600	.0433	.0518
Darien	559.5	19/w	477.0	26/7	.1716	.858	.4394	525.5	18,800	.0360	.0431
Elgin	652.4	19/w	556.5	26/7	.1853	.927	.5124	612.4	21,900	.0309	.0371
Flint	740.8	37/w	636.0	26/7	.1415	.991	.5818	695.5	24,400	.0272	.0327
Greely	927.2	37/w	795.0	26/7	.1583	1.108	.7282	870.4	30,500	.0217	.0263

ASTM B232 Standard:

Code Name	Size	No./Dia.of Stranding Wires		Approx. Overall Dia.	Approx. Weight	Code Name	Size	No./Dia.of Stranding Wires		Approx. Overall Dia.	Approx. Weight
	AWG or MGM	Alum.	ST.				AWG or MGM	Alum.	ST.
		No./mm	No./mm	mm	kg/km			No./mm	No./mm	mm	kg/km
Swanate	4	7/1.96	1/2.61	6.53	93	Tern	795	45/3.38	7/2.25	27.03	1300
Sparrow	2	6/2.67	1/2.67	8.01	129	Condor	795	54/3.08	7/3.08	27.72	1461
Sparate	2	7/2.47	1/3.30	8.24	148	Cuckoo	795	24/4.62	7/3.08	27.74	1461
Robin	1	6/3.00	1/3.00	9.00	163	Drake	795	26/4.44	7/3.45	28.11	1550
Raven	1/0	6/3.37	1/3.37	10.11	206	Coot	795	36/3.77	1/3.77	26.41	1184
Quail	2/0	6/3.78	1/3.78	11.34	259	Mallard	795	30/4.14	19/2.48	28.96	1728
Pigeon	3/0	6/4.25	1/4.25	12.75	327	Ruddy	900	45/3.59	7/2.40	28.73	1472
Penguin	4/0	6/4.77	1/4.77	14.31	412	Canary	900	54/3.28	7/3.28	29.52	1554
Waxwing	266.8	18/3.09	1/3.09	15.45	422	Rail	954	45/3.70	7/2.47	29.61	1560
Merlin	336.4	18/3.47	1/3.47	17.35	532	Catbird	954	36/4.14	1/4.14	28.95	1421
Linnet	336.4	26/2.89	7/2.25	18.31	656	Cardinal	954	54/3.38	7/3.38	30.42	1753
Oriole	336.4	30/2.69	7/2.69	18.83	737	Ortlan	1033.5	45/3.85	7/2.57	30.81	1690
Chickadee	397.5	18/3.77	1/3.77	18.85	629	Tanager	1033.5	36/4.30	1/4.30	30.12	1539
Ibis	397.5	26/3.14	7/2.44	19.88	775	Curlew	1033.5	54/3.52	7/3.52	31.66	1900
Lark	397.5	30/2.92	7/2.92	20.44	871	Bluejay	1113	45/4.00	7/2.66	31.86	1821
Pelican	477	18/4.14	1/4.14	20.70	754	Bunting	1192.5	45/4.14	7/2.76	33.12	1949
Flicker	477	24/3.58	7/2.39	21.49	877	Grackle	1192.5	54/3.77	19/2.27	33.97	2190
Hawk	477	26/3.44	7/2.67	21.80	931	Bittern	1272	45/4.27	7/2.85	34.17	2080
Hen	477	30/3.20	7/3.20	22.40	1044	Pheasant	1272	54/3.90	19/2.34	35.10	2335
Osprey	556.5	18/4.47	1/4.47	22.35	880	Skylark	1272	36/4.78	1/4.78	33.42	1895
Parakeet	556.5	24/3.87	7/2.58	23.22	1023	Dipper	1351.5	45/4.40	7/2.92	35.16	2210
Dove	556.5	26/3.72	7/2.89	23.55	1085	Martin	1351.5	54/4.02	19/2.41	36.17	2481
Eagle	556.5	30/3.46	7/3.46	24.21	1219	Bobolink	1431	45/4.53	7/3.02	36.24	2342
Peacock	605	24/4.03	7/2.69	24.20	1112	Plover	1431	54/4.14	19/2.48	37.24	2628
Squab	605	26/3.87	7/3.01	24.51	1180	Nuthatch	1510.5	45/4.65	7/3.10	37.20	2470
WoodDuck	605	30/3.61	7/3.61	25.25	1325	Parrot	1510.5	54/4.25	19/2.55	38.25	2773
Kingbird	636	18/4.78	1/4.78	23.88	1007	Lapwing	1590	45/4.77	7/3.18	38.16	2599

Aluminum Sectional Area		Stranding No. and Dia.		Approx. Overall Dia	Approx. Weight	Calculated Breaking Load	Calculated D C Resistance at 20oC	Code Name
AWG	(mm2)	Al.	St.	(mm)	(kg/km)	(KN)	(Ω/km)
6	13.30	6/1.68	1/1.68	5.04	53.75	5,303	2.157	Turkey
4	21.18	6/2.12	1/2.12	6.36	85.57	8,302	1.335	Swan
4	21.12	7/1.96	1/2.61	6.53	99.56	10,642	1.352	Swanate
2	33.59	6/2.67	1/2.67	8.01	135.70	12,653	0.854	Sparrow
2	33.54	7/2.47	1/3.30	8.24	158.60	16,171	0.852	Sparate
1	42.41	6/3.00	1/3.00	9.00	171.40	15,852	0.676	Robbin
1/0	53.52	6/3.37	1/3.37	10.10	216.20	19,455	0.536	Raven
2/0	67.32	6/3.78	1/3.78	11.30	272.00	23,529	0.426	Quail
3/0	85.14	6/4.25	1/4.25	12.80	344.00	29,417	0.337	Pigeon
4/0	107.20	6/4.77	1/4.77	14.30	433.40	37,055	0.268	Penguin
266800	135.00	18/3.09	1/3.09	15.50	430.50	30,519	0.213	Wax wing
266800	134.90	26/2.57	7/2.00	16.30	545.40	26,403	0.214	Partridge
300000	152.20	26/2.73	7/2.12	17.30	614.60	56,410	0.190	Ostrich
336400	170.20	18/3.47	1/3.47	17.40	542.90	38,487	0.169	Merlin
336400	170.60	26/2.89	7/2.25	18.30	689.90	62,918	0.169	Linnet
336400	170.50	30/2.69	7/2.69	18.80	784.50	77,267	0.170	Oriole
397500	201.60	24/3.27	7/2.18	19.60	762.50	65,099	0.143	Brant
397500	201.30	26/3.14	7/2.44	19.90	813.50	72,426	0.143	Ibis
397500	200.90	30/2.92	7/2.92	20.40	924.40	90,485	0.144	Lark
477000	242.3	18/4.14	1/4.14	20.70	772.60	52,302	0.119	Pelican
477000	241.7	24/3.58	7/2.39	21.50	914.90	73,243	0.120	Flicker
477000	241.6	26/3.44	7/2.67	21.80	975.50	86,011	0.120	Hawk
477000	241.3	30/3.20	7/3.20	22.40	1,110.00	105,611	0.120	Hen
556500	282.4	18/4.47	1/4.47	22.40	900.70	60,972	0.120	Osprey
556500	282.2	24/3.87	7/2.58	23.2	1,068.00	84,424	0.1030	Parakeet
556500	282.6	26/3.72	7/2.89	23.6	1,142.00	100,838	0.1030	Dove
556500	282.1	30/3.46	7/3.46	24.2	1,298.00	123,470	0.1030	Eagle
605000	306.2	24/4.03	7/2.69	24.2	1,159.00	95,861	0.0948	Peacock
605000	307.2	26/3.87	7/3.01	24.5	1,236.00	108,317	0.0944	Squab
605000	307.2	30/3.61	7/3.61	25.3	1,414.00	128,736	0.0945	Duck
605000	307.2	30/3.61	19/2.16	25.2	1,398.00	133,082	0.0945	Teal
636000	323.1	18/4.78	1/4.78	23.9	1,031.00	69,722	0.0890	Kingbirad
636000	323.0	24/4.14	7/2.76	24.8	1,222.00	101,038	0.0894	Rook
636000	322.5	30/3.70	19/2.22	25.9	1,472.00	14,029	0.0897	Egret
666600	337.2	24/4.23	7/2.82	25.4	1,276.00	105,478	0.0856	Flamingo
666600	338.3	26/4.07	7/3.16	25.8	1,366.00	117,258	0.0854	Gannet

Packaging & Shipping
XLPE/PVC insulated Power Cable
It is used to transmit and distribute power in power transmission and distribution system of 37kV or lower. It is generally applied to the fields including power, construction, mines, metallurgy, petrochemical indusry and communication in complete replace of oil immersed paper insulated power cable and in partial replace of PVC insulated power cable.

Using features:
1. Rated voltage: Uo/U: 26/35kV, 21/35kV, 12/20 kV (24 kV), 8.7/10kV, 8.7/15kV, 6/6kV, 6/10kV.
2. No. of core: Single-core, Three-core.
3. The highest allowed operating temperature of conductor for long-term working is 90ºC. In short-circuit (Max. Long-term is no more than 5 seconds). The highest temperature for conductor is no more than 250ºC.
4. D.C Resistance of the conductor complies with the stipulations of GB/T3956-1997.
5. The environment temperature should be no lower than 0ºC when lay. Otherwise it should be preheated.
6. The cable is laid without horizontal drop limit. The Min. Bending radius of three-core cable should be no smaller than 12 times of cable outer diameter.
7. Working Frequency Voltage Test:.
For cable with Uo of 3.6kV or lower: 2.5Uo+2kV/5min without puncture.
For cable with Uo of 3.6Kv~18kV: 3.5Uo/5min without puncture.
For cable with Uo of 21kV and 26 kV: 2.5Uo/30min without puncture.
8. Partial Discharge Test: The discharge volume should be no more than 10pC under 1.73Uo for the cable.

Type	Type	Name	No. of Cores	Nominal Cross-Section of Conductor(mm2)
Cu Core	Al Core		1	1.5--1000
YJV (YJY)	YJLV (YJLY)	XLPE Insulated,PVC(PE) Sheathed Power Cable	1	1.5--1000
YJV22 (YJV23)	YJLV22 (YJLY23)	XLPE Insulated,Steel Tape Armoured,PVC(PE) Sheathed Power Cable	2/3/4/5	1.5--400
YJV32 (YJLV33)	YJLV32 (YJLY33)	XLPE Insulated,Fine Steel Wire Armoured,PVC(PE) Sheathed Power Cable	2/3/4/5	1.5--400
YJV42 (YJLV43)	YJLV42 (YJLY43)	XLPE Insulated,Thick Steel Wire Armoured,PVC(PE) Sheathed Power Cable	2/3/4/5	1.5--400
ZR-YJV (ZR-YJY)	ZR-YJLV (ZR-YJLY)	XLPE Insulated,PVC(PE) Sheathed Flame-retardant Power Cable	2/3/4/5	1.5--400
ZR-YJV22 (ZR-YJY23)	ZR-YJLV22 (ZR-YJLY23)	XLPE Insulated,Steel Tape Armoured,PVC(PE) Sheathed Flame-retardant Power Cable	2/3/4/5	1.5--400
ZR-YJV32 (ZR-YJY33)	ZR-YJLV32 (ZR-YJLY33)	XLPE Insulated,Fine Steel Wire Armoured,PVC(PE) Sheathed Flame-retardant Power Cable	3+1/ 4+1/ 3+2	2.5--400
ZR-YJV42 (ZR-YJY43)	ZR-YJLV42 (ZR-YJLY43)	XLPE Insulated,Thick Steel Wire Armoured,PVC(PE) Sheathed Flame-retardant Power Cable	3+1/ 4+1/ 3+2	2.5--400

Specification

1)3.6/6(7.2)kV,3.6/6.6(7.2)kV,Three Cores,Al or Cu/XLPE/CTS/STA/PVC Armoured Power Cable
No.X Nominal Cross Section of Conductor	Nominal Diameter of Conductor	Nominal Thickness of Insulation	Nominal Thickness of Copper Tape Screen	Nominal Thickness of Inner Sheath	Nominal Thickness of Steel Tape Armouring	Nominal Thickness of PVC Sheath	Approx. Overall Diameter	Approx. Weight
								Al Conductor	Cu Conductor
No. X mm 2	mm	mm	mm	mm	mm	mm	mm	kg/m	kg/m
3 X 25	6	2.5	0.1	1.2	0.2	1.9	37.9	1.87	2.32
3 X 35	6.9	2.5	0.1	1.3	0.5	2	41.5	2.1	2.73
3 X50	8.2	2.5	0.1	1.3	0.5	2	44.3	2.37	3.22
3 X 70	9.7	2.5	0.1	1.4	0.5	2.1	47.9	2.77	4
3 X 95	11.3	2.5	0.1	1.4	0.5	2.2	51.6	3.21	4.91
3 X 120	12.8	2.5	0.1	1.5	0.5	2.4	55.4	3.69	5.84
3 X 150	14.2	2.5	0.1	1.5	0.5	2.5	58.6	4.15	6.85
3 X 185	15.9	2.5	0.1	1.5	0.5	2.6	62.5	4.73	8.11
3 X 240	18.3	2.6	0.1	1.6	0.5	2.7	68.5	5.62	10.05
3 X 300	20.4	2.8	0.1	1.7	0.5	2.9	74.5	6.55	12.11
3 X 400	23.2	3	0.1	1.9	0.8	3.2	83.6	8.78	15.86
3 X 500	26.4	3.2	0.1	2.1	0.8	3.4	93	10.52	18.85
2)6/10(12)kV,6.35/11(12)kV,,Three Cores,Al or Cu/XLPE/CTS/STA/PVC Armoured Power Cable
No.X Nominal Cross Section of Conductor	Nominal Diameter of Conductor	Nominal Thickness of Insulation	Nominal Thickness of Copper Tape Screen	Nominal Thickness of Inner Sheath	Nominal Thickness of Steel Tape Armouring	Nominal Thickness of PVC Sheath	Approx. Overall Diameter	Approx. Weight
								Al Conductor	Cu Conductor
No. X mm 2	mm	mm	mm	mm	mm	mm	mm	kg/m	kg/m
3 X 25	6	3.4	0.1	1.3	0.5	2	43.4	2.16	2.61
3 X 35	6.9	3.4	0.1	1.3	0.5	2	45.4	2.36	2.99
3 X50	8.2	3.4	0.1	1.4	0.5	2.2	48.8	2.69	3.54
3 X 70	9.7	3.4	0.1	1.5	0.5	2.3	52.4	3.1	4.33
3 X 95	11.3	3.4	0.1	1.5	0.5	2.4	56.1	3.56	5.26
3 X 120	12.8	3.4	0.1	1.5	0.5	2.5	59.5	4.04	6.19
3 X 150	14.2	3.4	0.1	1.5	0.5	2.6	62.7	4.49	7.19
3 X 185	15.9	3.4	0.1	1.6	0.5	2.6	66.6	5.12	8.49
3 X 240	18.3	3.4	0.1	1.7	0.5	2.8	72.4	5.99	10.42
3 X 300	20.4	3.4	0.1	1.8	0.5	3	77.5	6.86	12.42
3 X 400	23.2	3.4	0.1	1.9	0.8	3.2	85.4	8.97	16.05
3 X 500	26.4	3.4	0.1	2	0.8	3.4	93.7	10.65	19.5
3)8.7/10(15)kV,Three Cores,Al or Cu/XLPE/CTS/STA/PVC Armoured Power Cable
No.X Nominal Cross Section of Conductor	Nominal Diameter of Conductor	Nominal Thickness of Insulation	Nominal Thickness of Copper Tape Screen	Nominal Thickness of Inner Sheath	Nominal Thickness of Steel Tape Armouring	Nominal Thickness of PVC Sheath	Approx. Overall Diameter	Approx. Weight
								Al Conductor	Cu Conductor
No. X mm 2	mm	mm	mm	mm	mm	mm	mm	kg/m	kg/m
3 X 25	6	4.5	0.1	1.4	0.5	2.1	48.6	2.53	2.98
3 X 35	6.9	4.5	0.1	1.4	0.5	2.2	50.7	2.76	3.39
3 X50	8.2	4.5	0.1	1.5	0.5	2.3	53.9	3.1	3.95
3 X 70	9.7	4.5	0.1	1.5	0.5	2.4	57.4	3.51	4.74
3 X 95	11.3	4.5	0.1	1.5	0.5	2.6	61.2	4.05	5.75
3 X 120	12.8	4.5	0.1	1.6	0.5	2.6	64.7	4.56	6.72
3 X 150	14.2	4.5	0.1	1.6	0.5	2.7	67.9	5.04	7.74
3 X 185	15.9	4.5	0.1	1.7	0.5	2.8	71.9	5.66	9.04
3 X 240	18.3	4.5	0.1	1.8	0.5	3	77.7	6.56	11
3 X 300	20.4	4.5	0.1	1.9	0.8	3.2	84.1	8.39	13.96
3 X 400	23.2	4.5	0.1	2	0.8	3.3	90.5	9.71	16.79
3 X 500	26.4	4.5	0.1	2.1	0.8	3.5	98.8	11.45	20.57
4)12/20(24)kV, 12.7/22(24)kV,Three Cores,Al or Cu/XLPE/CTS/STA/PVC Armoured Power Cable
No.X Nominal Cross Section of Conductor	Nominal Diameter of Conductor	Nominal Thickness of Insulation	Nominal Thickness of Copper Tape Screen	Nominal Thickness of Inner Sheath	Nominal Thickness of Steel Tape Armouring	Nominal Thickness of PVC Sheath	Approx. Overall Diameter	Approx. Weight
								Al Conductor	Cu Conductor
No. X mm 2	mm	mm	mm	mm	mm	mm	mm	kg/m	kg/m
3 X 25
3 X 35	6.9	5.5	0.1	1.5	0.5	2.4	55.6	3.14	3.77
3 X50	8.2	5.5	0.1	1.5	0.5	2.5	58.6	3.49	4.34
3 X 70	9.7	5.5	0.1	1.5	0.5	2.6	62.1	3.93	5.16
3 X 95	11.3	5.5	0.1	1.6	0.5	2.6	65.7	4.46	6.16
3 X 120	12.8	5.5	0.1	1.7	0.5	2.7	69.4	5	7.15
3 X 150	14.2	5.5	0.1	1.7	0.5	2.8	72.6	5.49	8.19
3 X 185	15.9	5.5	0.1	1.8	0.5	3	76.9	6.16	9.53
3 X 240	18.3	5.5	0.1	1.9	0.8	3.2	83.9	7.87	12.31
3 X 300	20.4	5.5	0.1	2	0.8	3.2	88.6	8.96	14.52
3 X 400	23.2	5.5	0.1	2.1	0.8	3.5	95.4	10.35	17.43
3 X 500	26.4	5.5	0.1	2.2	0.8	3.7	103.7	12.45	20.23
5)18/30(36)kV,19/33(36)kV,Three Cores,Al or Cu/XLPE/CTS/STA/PVC Armoured Power Cable
No.X Nominal Cross Section of Conductor	Nominal Diameter of Conductor	Nominal Thickness of Insulation	Nominal Thickness of Copper Tape Screen	Nominal Thickness of Inner Sheath	Nominal Thickness of Steel Tape Armouring	Nominal Thickness of PVC Sheath	Approx. Overall Diameter	Approx. Weight
								Al Conductor	Cu Conductor
No. X mm 2	mm	mm	mm	mm	mm	mm	mm	kg/m	kg/m
3 X 25
3 X 35
3 X50	8.2	8	0.1	1.7	0.5	2.8	70.4	4.56	5.41
3 X 70	9.7	8	0.1	1.7	0.5	2.9	73.9	5.04	6.26
3 X 95	11.3	8	0.1	1.8	0.5	3	77.7	5.62	7.32
3 X 120	12.8	8	0.1	1.9	0.8	3.2	82.8	6.99	9.15
3 X 150	14.2	8	0.1	1.9	0.8	3.2	85.8	7.56	10.26
3 X 185	15.9	8	0.1	2	0.8	3.3	89.9	8.3	11.67
3 X 240	18.3	8	0.1	2.1	0.8	3.5	95.7	9.36	13.79
3 X 300	20.4	8	0.1	2.2	0.8	3.6	100.6	10.51	16.07
3 X 400	23.2	8	0.1	2.3	0.8	3.8	107.2	11.99	19.07
3 X 500	26.4	8	0.1	2.4	0.8	4	120.1	14.15	23.85

Packaging & Shipping
Control Cable
Used as power and connecting cables in mechanical engineering for tooling machinery, control unit, production lines, transportation equipment, conveyor and assembly lines as well as in plant construction under the circumstance that the rated voltage is up to 450/750V AC.
Product Type

Type	Name	Section Area (mm2)	No.of Core	Application Site
KVV	Copper Conductor,PVC Insulated and Sheathed Control Cable	0.75 1.0 1.5 2.5	2-16	Permanent installation indoors, in cable ditches or pipes
		4 6	2-14
		10	2-10
KVVP	Copper Conductor PVC Insulated and Sheathed,Braiding Shielded Control Cable	0.75 1.0 1.5 2.5	2-61	Permanent installation indoors, in cable ditches or pipes where shielding is required
		4 6	2-14
		10	2-10
KVVP2	Copper Conductor PVC Insulated and Sheathed,Copper-tape Screened Control Cable	0.75 1.0 1.5 2.5	4-10	Permanent installation indoors,i n cable ditches or pipes where shielding is required
		4 6	7-61
		10	4-10
KVV22	Copper Conductor PVC Insulated and Sheathed,Steel tape Armored Control Cable	0.75 1.0 1.5 2.5	7-61	Permanent installation indoors, in cable ditches,Be able to withstand stronger external mechanical force
		4 6	4-14
		10	4-14
KVVR	Copper Conductor PVC Insulated and Sheathed,Flexible Control Cable	0.5-2.5	4-61	Installation indoors where flexibility and movability are required
KVVRP	Copper Conductor PVC Insulated and Sheathed,Braiding shielded Flexible Control Cable	0.5 0.75 1.0	4-61	Installation indoors where flexibility shielding and movability are required
		1.5 2.5	4-48
KYJV	CopperConductor XLPE Insulated and PVC Sheathed Control Cable	0.75 1.0 1.5 2.5	2-16	Permanent installation indoors, in cable ditches or pipes
		4 6	2-14
		10	2-10
KYJVP	Copper Conductor XLPE Insulated,Braiding Shielded,PVC Sheathed Control Cable	0.75 1.0 1.5 2.5	2-61	Permanent installation indoors, in cable ditches or pipes where shielding is required
		4 6	2-14
		10	2-10
KYJV22	CopperConductor,XLPE Insulated,Steel-tape Armoured,PVCSheathed Control Cable	0.75 1.0 1.5 2.5	7-61	Permanent installation indoors, in cable ditches,pipes or underground Be cable to with stand stronger external mechanical force
		4 6	4-14
		10	4-10
KYJVP2	CopperConductor,XLPE Insulated,Copper tape Screened,PVCSheathed Control Cable	0.75 1.0 1.5 2.5	7-61	Permanent installation indoors, in cable ditches or pipes where shielding is required
		4 6	4-14
		10	4-10
KYJVR	CopperConductor,XLPE Insulated,PVCSheathed Flexible Control Cable	0.5-2.5	4-61	Installation indoors where flexibility and movability are required
KYJVRP	CopperConductor,XLPE Insulated,Braiding Shielded,PVC Sheathed Flexible Control Cable	0.5 0.75 1.0	4-61
		1.5 2.5	4-48	Installation indoors where flexibility shielding and movability are required

Concentric Cable
The concentric cable is used as electric service entrance from the power distribution network until the meter panel (especially where it is required to prevent "black" losses or electric power robbery), and as feeder cable from the meters panel until the panel or general distribution panel, just as it is specified in the National Electrical Code.
Specification

ASTM 600/1000v
Core	AWG	Structure Size (mm)									Copper cable (kg/km)
		Conductor		Insulation	Concentric conductor		Outer sheath
		Single wire		XLPE	Single wire		UV-PVC
		No.	Dia.	Thick	No.	Dia.	Thick		Dia.
1	16	7	0.49	1.14	39	0.321	1.14		6.82		81.46
1	10	7	0.98	1.14	34	0.511	1.14		8.67		172.04
1	8	7	1.23	1.14	25	0.643	1.14		9.68		221.58
1	6	7	1.55	1.14	25	0.813	1.14		10.98		160.50
1	4	7	1.96	1.14	27	1.020	1.14		12.62		509.26
IEC 60502-1 IEC 60228 600/1000v
Size (mm2)	Structure Size mm									Copper cable (kg/km)
	Concuctor			Insulation	Concentric conductor		Outer sheath
	Single wire		Dia.	PVC	Single wire		UV-PVC
	No.	Dia.		Thick	No.	Dia.	Thick	Dia.		(kg/km)
10	7	1.35	4.05	1.55	20	0.85	1.4	11.79		301.55
16	7	1.7	5.1	1.55	32	0.85	1.4	12.84		431.7
25	7	2.14	6.42	1.6	29	1.13	1.5	15.02		647.46
Aluminum Cable
16	7	1.7	5.1	1.55	26	1.13	1.4	13.42		244.16
25	7	2.14	6.42	1.6	29	1.13	1.5	15.02		307.3
35	19	1.53	7.65	1.65	27	1.35	1.6	16.99		390.15

Company Profile Zhengzhou Jinshui Industry & Commerce Co.Ltd is located in the national class Zhengzhou high and new technology industries zone in Zhengzhou, Henan province. We have owned a number of exclusive essential manufacturing technologies and have passed the ISO 9001 Quality Management System, ISO 14001 Environmental Management System, OHSAS18001 occupational Heath Management System, ISO 10012 Measurement Management System, and others from China and abroad.
We have been engaged in producing electric cable and wire for nearly 20 years, and we are also a 12-year gold supplier. And we are confident that we can offer the best service and quality for you.
Our product range is as follows:
*Bare conductors(AAC, AAAC, ACSR, Galvanized steel wire)
*Aerial Bounded Cable (Duplex, Triplex, Quadruplex)
* PVC insulated wire (Rated voltage to 450/750V)
*THHN/THWN wire
*PVC insulated Power Cable
*XLPE insulated Power Cable
*Rubber sheathed Cable
*Control Cable
*Welding Cable
*Cable Accessories
We take part in many fairs and exhibitions in China and abroad. Our aim is to be our customer's factory in Zhengzhou, China.
We are here to help you place orders
of cost-effective electric cable and keep tracking your products and shipment.

Certifications
Exhibition
Our Factory

FAQ 1. Who are we?
We are based in Henan, China, start from 2001,sell to Southeast Asia(39.00%),North America(20.00%),South America(15.00%),Mid East(15.00%),Africa(10.00%),Domestic Market(1.00%). There are total about 11-50 people in our office. 2. How can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment; 3.What can you buy from us? Wire,Cable 4. Why should you buy from us not from other suppliers? Jinshui Wire & Cable Group is also a key company of high and new technology. We have more than 20years export experience and know most of standards well. we can produce more than 1,400 types of cables and wires in scores of categories. 5. What services can we provide? Accepted Delivery Terms: FOB,CIF; Accepted Payment Currency:USD,EUR,HKD,CNY; Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card; Language Spoken:English,Chinese,Spanish Q: How long does it take get my inquiry replied? A: Mostly the inquiry will be replied within 12 hours. And the quote will be sent to you in 1-3 days. It depends on the technical parameters and requirements of the cable. We will give you a reasonable and accurate quote.
Q: Can I get samples before placing the order? A: You will get a sample for free if we have the storage of that cable.
Q: What's the MOQ of your product? A: The MOQ of our most product is 1000 meters. But if there's any exceptional situation, we can make some negotiations.Fore More Information, Please do feel free to contact us! Welcome your kind inquiry!

---

>> White Kraft Paper Salad Soup Noodles Bowl Forming and Making Machine China Supplier Manufacturer Price for Sale
>> Kaisen indoor shoebox lighting with 40-300W
>> Kitchen Scales Sf-400 Black Color OEM 10kgs Different Colors Available
>> New style Chinese top brand customized aluminium casement door with glass
>> Solar Panel Shredding and Separating Machine Photovoltaic Solar Panels Recycling Machine
>> 100PCS Stainless Steel 304 Finish Flat Head Rivet Nut
>> 85045-60090 AUTO Headlamp Washer Cover For Toyota Land Cruiser Prado 2013-2016
>> Plough-Shear Mixer for Efficient Tile Adhesive Powder Processing
>> Taijia ZD410 Concrete Slab Thickness Detector digital thickness gauge
>> Double Head Aluminum Window Profile Digital Cutting Saw Machine
>> Taijia variable area water flow rate meter digital Dual Channel Ultrasonic FlowMeter flow meter
>> Lamination Machine for PP Woven Bags (Sj-Fmz Series)
>> Wholesale auto parts for bus tail Light system 6126 tail Light HC500X410 rear tail lamp For Golden Dragon bus
>> 6 Ton Weight Mini Earth Moving Machine Original Good Condition Wy60 Crawler Excavator for Sale
>> Rth-1400A4 Label A4 Paper Sheeter Kraft Paper Roll Sheet Cutting Machine with Two Frame
>> Industrial Liquid Paint Chemical Prices Automatic Mixing Paint Mixer Machine
>> Hiland 2023 Tubular Motor Receiver TM516X with 30 Transmitters Stored for Automatic Gates
>> 16cbm Self-Driven Feeding Equipment for Large Scale Farming
>> Baby turban nylon headwrap Kids Girl Handmade Soft Headbands with Bow Solid Color 18Colors
>> 260 Slices 0.35mm Textile Machine Weaving Loom Parts
