X6336 Hobby Horizontal Milling Machine Cutting Metal

Product Description

X6336 Hobby Horizontal Milling Machine Cutting Metal
Product Description
The product is easy to operate and reliable. Available for all kinds of cylindrical milling cutter, milling cutter, angle cutter, milling cutter and face Various plane, inclined plane, groove, etc.. If the use of appropriate milling machine accessories, can be processed gear, cam, arc groove
And other special shaped parts, such as the spiral surface, the configuration of universal milling head, round table, the worktable size of the machine can be further expanded,Large machine tool use range, according to user needs can be configured to display device.
The Main Specification:

Specification	X6336
Spindle taper	NT 40 vertical
	NT 50 horizontal
Milling head tilt	Left/right:90 degree
Spindle travel (mm)	127
Spindle speeds range (r.p.m)	66-4540(vertical 16 step)
	60-1800 (horizontal 12 step)
Distance from spindle to column(mm)	155-700
Spindle nose to table top (mm)	100-600 (vertical) 0-400 (horizontal)
Arm travel (mm)	550
Rotary arm	360°
Table size (mm)	1500*360
Max. travel of table (mm)	1000*320*400
T-slot number width distance (mm)	3/18/80
Max.table load	800kg
Feed speed (rpm)	30*555
Main motor power (kw)	3.7(optional:7.5HP )Vertical
	4 (Horizontal)
Packing size(mm)	2600*2100*2300
N.W/G.W(kg)	2500/2700 kg

Standard Accessories: Optional Accessories
1. Drill chuck 1. DRO on X,Y,Z--AXIS
2. mill chuck 2. Clamping kit
3. Inner hexagon spanner 3. Universal dividing head
4. Work light 4. Rotary work table
5. Reduction sleeve
6. Draw bar
7. Spindle arbor
8. Wrench
9. Machine vice
10.Horizontal milling arbor
Details Display
Company Profile
Packing shipping
For machine: usually by sea;
For documents: by international express, eg. DHL,TNT or EMS.
For packing :Free fumigation plywood packaging steel base
our service
1. Technical support online service provided.
2. Technical files service provided.
3. Machine operation video provided
4. On-site training service provided.
5.Spare parts replacement and repair service provided.
6 All of the questions will be replied within 8 hours
7. If you need to develop products with your own specification, we can help you to work it out.
8. Always be honest, never lie to customer, and never declare anything we don't have
Company Information
Since 1996,20 years' history for machine tool manufacturing
10 years' history for export
Total 2 manufacturing bases in china
Sino-germany technology cooperation
Production of 8 categories, more than 130 kinds of products
Set up design&research center at TAIWAN
Exported to total 48 countries in the world covered most areas
One-stop shopping for nearly all other types' machine tools
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
