Established Factory Tire Double Shaft Shredder Double Roller Waste Tire Recycling Crusher Equipment Tire Recycling China Price Machine for Tire Recycling

Product Description

https://hvstgroup.en.made-in-china.com/contact-info.htmlProduct Descriptiontire recycling machine tire recycling machinery in rubber raw material machinery
HVST's main focus is to provide our customer cost-effective waste recycling system applied in all kinds ofwaste recycling like tire/plastic/wood/metal/car/pcb board recycling and could provide output products like chips(50-150mm),mulches(10-30mm)granules(1-6mm),powder(30-120 mesh) and othersize as customer required For tire recycling plant, our normal capacity is 100kg/h-5000kg/h and the most popular capacity is 500kg/h, 1000kg/h, 2000kg/h,3000kg/h. You can choose the suitable one as per your requirements.Product Parameters
Tire ShredderWaste tire less than 1200mm and rubber materials can be crushed into 50*50 mm block. The machine consists of rack,cavity, motor, hydraulic coupling, reducer, a group of moving blades, two sets of blades, screen, hydraulic system.

Model	Input size	Output size	Capacity	Motor	Weight
TS-800	800mm	50*50mm	1-2t/h	2*22kw	8t
TS-1200	1200mm	60*60mm	3-5t/h	2*37kw	14t
TS-1600	1600mm	50-150mm	6-8t/h	2*45kw	18t
TS-1800	1800mm	50-150mm	7-10t/h	2*55kw	23t

Rubber GrinderInput materials≤50mm tire rubber blocks Finally products ≤20mm. and can remove 96% of the tire steel wire Motor: as per request Reducer: as per request

Rasper	LK-R315	LK-R132	LK-R90	LK-R75	LK-R55	LK-R45
Motor	Siemens	Siemens	Siemens	Siemens	Siemens	Siemens
Power	315kw	132kw	90kw	75w	55w	45kw
Voltage	As per request
Cutting chamber	697*1562	742*1200	550*1000	550*800	450*800	45-*600
Equipment dimensions mm	6217*2168*3561	2010*2562*4110	2095*2180*4105	1995*1980*4105	1720*1730*2316	1400*1200*2260
Hopper opening	1726*877*906	1412*902*1410	1182*700*1255	982*700*1255	922*580*916	722*580*916
Equipment weight	24000kg	6100kg	4200kg	3500kg	1850kg	1700kg
Capacity	3-6T/H	1.5-3T/H	1-1.5T/H	700KG-1T/H	500-700KG/H	300-500KG/H
Final product	10-30mm	10-30mm	10-30mm	10-30mm	10-30mm	10-30mm

rubber grinderThe rubber grinder is a device that pulverizes 2-6mm pure rubber granules into a fine powder of10-140 mesh at room temperature. Motor: as per requestProduct size: one or more sizes are discharged at the same time

Granulator	LK-G90	LK-G45	LK-G37	LK-R75	LK-R55	LK-R45
Motor specifications	Electric-Siemens			Siemens	Siemens	Siemens
Power	90kw	45kw	37kw	75w	55w	45kw
Voltage	As per request
Cutting chamber L*W	742*1200	580*1000	580*800	550*800	450*800	45-*600
Equipment Dimensions	2150*2250*2950	1765*1900*2435	1765*1660*2435	1995*1980*4105	1720*1730*2316	1400*1200*2260
Equipment weight	5600kg	3300kg	2950kg	982*700*1255	922*580*916	722*580*916
Hopper opening L*W*H	895*1434*1160	602*994*916	602*794*916	3500kg	1850kg	1700kg
Capacity	800-1500kg/h	500-800kg/h	300-500kg/h	700KG-1T/H	500-700KG/H	300-500KG/H
Final product	1-6mm	1-6mm	1-6mm	10-30mm	10-30mm	10-30mm

Miller	LK-M280
Motor Specifications	Electric-Siemens
Power	30Kw*4
Voltage	as per request
Equipment Dimensions L*W*H	2404*1100*1093
Equipment Weight	5000Kg
Capacity	400-600kg/hr
Final Product	30-120 mesh

Customize your solution
If you need rubber granule with a mesh size <20, please choose ourRUBBER GRANULE PRODUCTION LINE Rubber Granule Sze: 1-5 mmCrush tire blocks(3-5cm) into 1-6mm rubber granules and separate the steel wire and nylon fiber from the rubber granule to get pure finished products. It can produce 1-2mm 2-4mm 4-5mm three different size granules at the same time.If you need rubber powder with a mesh size ≥20, please choose ourRUBBER POWDER PRODUCTION LINE Rubber Powder Size: 20-40 Mesh(Normally)Crush tire blocks(3-5cm) into rubber powder and separate steel wire and nylon fiber from rubber powder to get pure finished products.If you need rubber powder with a mesh size 20-120 meshthe Fine Grinder System is needed. Rubber Powder Size: 20-120 Mesh (According to customer requirements)The fine grinder is applied to crush rubber powder or rubber granule into more smaller size and it can reach 120 mesh.Customer feedback
Why Choose Us
Zhengzhou Harvest Machinery Co., Ltd HVET's main focus is to provide our customer cost-effective waste recycling system applied in all kinds of waste recycling like tire/plastic/wood/metal/car/pcb board recycling and could provide output products like chips(50-150mm), mulches( 10-30mm), granules (1-6mm), powder (30-120 mesh) and other size as customer required. HVET also offers machines for specialized markets. The most important to theHVET family of products is the Tire Shredding System. These machines are designed to process used car and truck tires. We offer complete systems to produce separated crumb or powder.Our Services1. Provide the floor space and size required for recycling machine.2. Provide the complete recycling line layout and its CAD drawing.3. Install & Training:We will assemble the main parts, then mark all the joint parts and send videos to guide the installation and training . We can arrange our engineer to client's working site, and client needs to afford the air tickets, hotel, meals and salary for our engineer4. Global inspection service: Our company provides a free inspection service within one year from the end of installation.
5. Repair service: If the abnormal damage occurs during the warranty period, the engineer maintenance fee will be paid.

---
