| (Main parameter) | | (Units) | (Parameters) |
| Chasis |
| EngineModel | | | QSX15 |
| RatedPower/RotarySpeed | | kW/rpm | 410/1950 |
| Track width(margin) | | mm | 4900 |
| Track shoe width | | mm | 800 |
| Traction force | | kN | 668 |
| RotaryDrive |
| Max.output torque | | kN.m | 405 |
| Rotaryspeed | | rpm | 6~27 |
| Max.pull-down piston push | | kN | 330 |
| Max.pull-down piston pull | | kN | 400 |
| Max.pull-down piston strlke | | mm | 6000 |
| Mainwinch |
| Max.pulling force | | kN | 385 |
| Max.pulling speed | | m/min | 75 |
| Wire Rope Diameter | | mm | 36 |
| Auxiliary winch |
| Max.pulling force | | kN | 100 |
| Max.pulling speed | | m/min | 66 |
| Wire Rope Diameter | | mm | 20 |
| MastRake |
| Forwards backwards | | | 5 |
| Sidebackwards | | | ±4 |
| Hydraulic system |
| Max.working pressure of main pump | | MPa | 33 |
| Drilling hole |
| Max.Drilling Diameter | | mm | 2600/3000() |
| IThe max.drilling depthI | | m | 99(18m) |
| The max.drilling depth | | m | 66(18m) |
| Main machine |
| Total working weight | | t | 120 |
| Transportation weight(Removethe rotating device) | | t | 97 |
| Transporting state sizeI | | mm | 19605×3620×3588 |
| Working statesize | | mm | 11135×4900×26233 |
| Recommended drill pipe type |
| Friction rod configuration | | | MZ 530-6×18 m |
| Machine lock lever configuration | | | JS 530-4×18 m |
