Symbol
| Parameter
|
Chipset
| Qualcomm Atheros QCN9074
|
WLAN Host Interface
| PCI Express 3.0 Interface
|
System Memory
| 2Mbit serial I²C bus EEPROM
|
Standard Operating Voltage
| 5V
|
Operating Systems
| QSDK
|
Host Interface
| M.2 E Key
|
Antenna Cable / Port
| 4 x MMCX Connectors,4T4R
|
Frequency Range
| 2.412GHz-2.472GHz
|
Data Rates for WALN
| 2.4GHz, max 23dBm per chain, up to 1147 Mbps
|
Channel Spectrum Widths for WLAN
| Support 20/40MHz at 2.4GHz
|
Modulation Techniques
| OFDMA: BPSK, QPSK, DBPSK, DQPSK,16-QAM, 64-QAM, 256-QAM,1024-QAM
|
Temperature Range
| Operating: -20°C to 70°C, Storage: -40°C to 90°C
|
Humidity
| Operating: 5% to 95% (non-condensing), Storage: Max. 90% (non-condensing)
|
Certification
| TBD
|
Power Consumption
| TBD
|
Reference Design
| PN01.1
|
Dimensions (WxHxD)
| 57mm x 63mm x 6mm
|
