| US$140.00 | 100 Pieces (MOQ) |
| Max capacity | 30kg | 60kg | 100kg | 150kg |
| e / Test division | 10g | 2g | 5g | 10g |
| d1 / Display division | 5g | 1g | 2g | 5g |
| d2 / Display division | 2g | 0.5g | 1g | 2g |
| Platform size | 30*40cm | |||
| Max capacity | 30kg | 60kg | 100kg | 150kg | 300kg |
| e / Test division | 10g | 2g | 5g | 10g | 100g |
| d1 / Display division | 5g | 1g | 2g | 5g | 5g |
| d2 / Display division | 2g | 0.5g | 1g | 2g | 2g |
| Platfrom size | 40*50cm | ||||
| Rated load | kg | 0.6 / 1 / 2 / 3 / 5 / 8 / 10 / 15 / 20 / 30 /40 | ||
| Accuracy class | C3D | C3 | C3G | |
| Max number of load cell verification intervals | nmax | 2500 | 3000 | 3000 |
| Minium load cell verification intervals | Vmin | Emax/5000 | Emax/7000 | Emax/11000 |
| Combined error | %FS | ≤±0.03 | ≤±0.02 | ≤±0.015 |
| Creep | %FS/30min | ≤±0.02 | ≤±0.016 | ≤±0.012 |
| Temp. effect on sensitivity | %FS/10°C | ≤±0.02 | ≤±0.0175 | ≤±0.013 |
| Temp. effect on zero output | %FS/10°C | ≤±0.028 | ≤±0.02 | ≤±0.0127 |
| Sensitivity | mv/v | 2.0±0.02 | ||
| input resistance | Ω | 406±6 | ||
| output resistance | Ω | 350±3 | ||
| insulation resistance | MΩ | ≥5000 (50VDC) | ||
| Zero output | %FS | ≤±2 | ||
| Compensated temperature range | °C | -10~40 | ||
| Operating temperature range | °C | -35~65 | ||
| Recommended excitation voltage | V | 5~12 (DC) | ||
| Max excitation voltage | V | 16 (DC) | ||
| safe over load | %FS | 150 | ||
| ultimate over load | %FS | 300 | ||
| Four comer error | 0.02% load value | |||
| Max table size | mm | 250*250 | ||
| Method of connecting wire | Input (+): Red input (-) : Black Output (+): Green Output(-): White | |||
