Ql1350tz-PUR Acrylic Sheet Laminating Machine

Product Description

Product Description
QL1350TZ-PUR acrylic sheet laminating machine
This production line adopt the special precise hotmelt glue system .This machine is specialize in sticking on panel and multiplayer board, it is suitable for produce high-glossy , panel ,cabinet ,furniture door, honeycomb board and foam board sticking .etc .
1.Laminate material :High-gloss pvc , acrylic , HPL, PVC board and metal board ,PE, PET ,PVC, veneer , paper .ect.
2.Based panel material :MDF board ,chipboard, plywood, gypsum board, HPL, foam board ,aluminum panel ,steel panel.
3.Glue: PUR hotmelt glue .
4.User :Furniture ,cabinet ,panel door producer ,new building material factory ,high-grade decoration board factory .
Technical parameters

Panel preheating	One heating channel
PUR glue machine	55 gallans
silica gel glue coating roller	Φ240*1pc
steel glue roller	Φ190*1pc
Total glue spread roller	4 rollers
steel glue roller heating	adopt a 15 kw oil heating machine
Glue heating after coating	ONE HEATING BOX
shaft for film	Two
Loading height of the hoist	1.5Ton
silica gel pressing roller	Φ240mm*2pc
Hot steel pressing roller	Φ240mm*2pc
Drive motor Power	9KW
PUR glue melt machine power	20KW
Heating power	24KW
Dust clean power	0.37KW
Lifting table power	6KW
Total power	72.37kw
Max.glue coating width	1300mm
Max.working width	1300mm
Processing thickness	3-50mm
frequency converter	HZ
Motor	SIEMENS Motor
Electric parts	CHINT+Schneider
working speed	2-18m/min
Voltage	380V/50Hz
Machine weight	6500kg
Overall size	23000*2300*1700mm

Detail information
PUR laminating machine is suitable for laminating roller film(Matt PVC film,high gloss PVC film,melamine paper,PET film...) and sheet type material(Acrylic,CPL,HPL,aluminum sheet) on different kind of flat panel(particle board, MDF board, WPC board, PVC board,plywood, plastic board, gypsum board foamed plastic board, zinc board, aluminum board, steel board, etc.)This machine for panel size 1220*2440mm,we can also make the machine suitable for 1830*3660mm panel which need addition charge.
Woodworking PUR hot melt glue laminating machine
This machine for panel size 1220*2440mm,we can also make the machine suitable for 1830*3660mm panel which need addition charge.
Woodworking PUR hot melt glue laminating machine
Woodworking PUR hot melt glue laminating machine
Woodworking PUR hot melt glue laminating machine
Woodworking PUR hot melt glue laminating machine
Final product
Woodworking PUR hot melt glue laminating machine
Our factory
Qingdao Qili Machinery CO.,LTD has more than 12 years experience for produce Woodworking Machine (Paper and PVC laminating Machine, PUR Laminating Machine, Profile Wrapping Machine, CNC router and vacuum membrane press machine.)
Our company makes great efforts in the design, development and manufacture of cover adorn machines for many years, and we have accumulated rich experience in products' research and development. We never stop to advance and pursuit best.
The convenient economical design and durable subassemblies help customers use facility easily. We are ready to introduce advanced technology into our new products. For each machine, we really concern about its function and practicability. We believe a good reputation roots from strong quality guarantee. Only with best durable, reliable and credible quality merchandise could win customers' heart, and our present leading position in cover adorn machine field results from it.
After sale service:
One-year warrant for factory defeat,6 months warranty for electric components,we will change new parts under warranty free of charge,hower we don't take responsibilities for parts due to natural wear-out and operation by mistic or any misuses.We promise a whole-life after-sale maintenance and support,call us any time.
Note:Oversea customer may need to undertake the roundway tickets,provide acommodation and food for our after-sale stuff if need our stuff flies over,if not we can only support you by email,videos,camera,ect. will spare no solve problem.
Please feel free to contact us

---
