Full Servo Baby Pull up Pants Machine Product Description
| CSG-BPUP700 FULL SERVO BABY PULL UP PANTS MACHINE |
|
| Product Stucture |
| 1 | 3-pcs type baby pull up pants |
| 2 | 2-pcs type baby pull up pants |
| 3 | 2pcs and 3-pcs type baby pull up pants compatible |
| Main Technical Parameters |
| 1 | Supply,3 phase,380V,50Hz |
| 2 | Power:500KW(Excluding hot melt applicator and Compressor) |
| 3 | Production speed:450/600/700pcs/min |
| 4 | Qualification:≥97% |
| 5 | Outside dimension(m):46 x 10x 5.5 (L×W×H)( for reference) |
| Main Function and Features |
| (I)Mechanical part |
| 1 | Pulp SAP mixing product and laminating core product are compatible |
| 2 | High-density ultra-thin fluff core forming drum system,good absorbability,and low reverse osmosis |
| 3 | Waist Sealing:Ultrasonic sealing process, support for tension customization,soft feel,and good appearance |
| 4 | Waist elastic lamination is made of glue-free technology with ultrasonic, which improves the softness of the waist and saves costs |
| 5 | 3D material online making application (option) |
| 6 | With web guiding system |
| 7 | Packing machine or stacker (option) |
| 8 | Dust collection filter system (option) |
| (II)Electric part |
| 1 | Full servo motor drive and PLC control |
| 2 | One button for size change, quick and less waste |
| 3 | High-precision tension control system,active un-winding and auto-splicing system |
| 4 | i-MAS Intelligent equipment mangement and analysis system |
| 5 | Material auto-splicing joint limit at 3m, and decrease material wastage |
| 6 | Material auto-splicing inspect,broken and lost alarm system |
| 7 | Material picture online positioning application |
| 8 | Vision inspection system (option) |
| 9 | Elastic BTSR tension control system, single tension adjust(option) |
Sales Service
ZHEJIANG NEW YUHONG INTELLIGENT EQUIPMENT CO.,LTD
With an impressive legacy spanning nearly three decades, ZHEJIANG NEW YUHONG INTELLIGENT EQUIPMENT CO., LTD excels in the design and manufacturing of cutting-edge disposable hygiene machines. Our expertise encompasses a wide array of innovative machines, including Sanitary Napkin Machines, Under Pad Machines, and both Adult & Baby Diaper Machines. We proudly deliver more than 30 state-of-the-art production lines each year, offering thousands of meticulously crafted machines to satisfied clients worldwide. Our esteemed reputation echoes across China, South-East Asia, the Middle East, and Europe, reflecting our commitment to quality and excellence.
