Coloum Vertical Drilling Machine Zx-Bhc/Zx-Bpc/Zx-Bhc1/Zx-Bpc1

Product Description

Characters:
Gear hardened , large driven torque; B1 type optional 2-speed motor , wide
spindle speed range.
"P" With collantsystems "H" Without collant systems.

Specification:

Model No.	ZX-40BHC/ZX-40BPC	ZX-40BHC1/ZX-40BPC1
Moving
Max.Drilling Capacity	Steel 32mm Cast Iron 40mm	Steel 32mm Cast Iron 40mm
Width of face milling	80 mm	80 mm
Diameter of vertical milling	22 mm	22 mm
Diameter of column	115 mm	115 mm
Spindle
Spindle travel	110 mm	110 mm
Distance spindle axis to column generating line	261.5mm	261.5mm
Max.Distance spindle nose to table	745 mm	745 mm
Max.Distance spindle nose to base	1245 mm	1245 mm
Spindle taper	MT4 or R8	MT4 or R8
Spindle speeds range	50~1250 r/min	50~2500 r/min
Spindle speeds series	6	12
Spindle feeds	0.12 0.18 0.25 mm/r	0.12 0.18 0.25 mm/r
Dimension of worktable surface	585×190mm	585×190mm
Table travel	370×140×515 mm	370×140×515 mm
Dimension of base	635 ×460 mm/690×520 mm	635 ×460 mm/690×520 mm
Other
Overall height	1760/1810 mm	1760/1810 mm
Main motor	Single-phase 1100w Three-phase 1500 w	Single-phase 1100w Three-phase 1500 w
Coolant motor	-/40w	-/40w
G.W/N.W	360/320 kg 390/350 kg	380/340 kg 410/370 kg
Packing dimension	72×74×192/72×74×198 cm	72×74×192/72×74×198 cm

FAQ
1.How can I choose the most suitable machines?
Please advice your technical requirements, or workpiece information or just send drawing, we can provide most suitable machine model information to you.
2.What's your main products of your company?
We specialized in all kinds of metal-working machines, such as CNC Lathe Machine, CNC Milling Machine, Vertical Machining Center, Lathe Machines, Drilling Machine, Radial Drilling Machine, Sawing Machine, Shaper machine, laser and so on.
3.Where is your factory located?
Production bases are in Canton, Jiangsu and Shandong.
4.What is your trade terms?
FOB , CFR and CIF all acceptable.
5.What's the MOQ?
1 SET.
6.Are you a manufacturer?
By collaborating of more than 10 years with selected manufacturers that possess different product advantages, integrating foreign demands, we have built out full range high quality product line which enjoy better pricing and lead time while we can execute production monitor and quality assurance, and we provide comprehensive high-quality pre-sales and after-sales services.
7.What's the Payment Terms?
T/T, 30% initial payment when order, 70% balance payment before shipment Irrevocable LC at sight.
8.How to get quotation?Place an order? How about the delivery time?
Just send us an inquiry or contact us with online service / WhatsApp advising your technical requirements or workpiece information, we will revert you shortly with our catalogue , quotation and other details you need. For standard models, lead time is around 30-60 days after payment received.
9.What service we can offer?
1). 12 months warranty.
2). Free technical support online service via email, telephone, video meeting etc.
3). On-site commissioning, testing and training service.
4). Spare parts and consumable parts supply and machine repair service.
5). All of the questions will be replied within 24 hours.

---
