| Model | CXH-S500 | CXH-S800 | CXH-S1000 | CXH-S1600 |
| Packaging diameter | ≤500mm | ≤800mm | ≤1000mm | ≤1600mm |
| Packaging length | no limit | no limit | no limit | no limit |
| Packing material | W≤250mm | W≤250mm | W≤250mm | W≤250mm |
| Conveying speed | 3～8m/min | 3～7m/min | 3～6m/min | 2～4m/min |
| Rotary speed | 50～80r/min | 50～70r/min | 40～60r/min | 20～40r/min |
| Height of conveying table | 800mm | 1000mm | 1000mm | 1000mm |
| Load-bearing | 2000kg | 3000kg | 6000kg | 10000kg |
| Overlap range | 20%～70% | 20%～70% | 20%～70% | 20%～70% |
| Power | 7.0kw | 9.0kw | 12.0kw | 16.0kw |
| Electricity | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Equipment weight | 2500kg | 3000kg | 3500kg | 5000kg |
| Equipment dimension | 19500×3200×2600mm | 19500×3200×2800mm | 19500×3500×3100mm | 19500×3800×3600mm |
