Z94-3c Nail Making Machine

Product Description

Z94 SERIES HIGH SPEED LOW NOISE ,AUTOMATIC NAIL MAKING MACHINE Function:
1. This nail making machine adopts piston structure to ensure the high working speed, low noise and less chance of impact characteristics.
2. Especially it can make excellent quality of common nail , coil nail and other special-shaped nail .
Specification :

Model	Diameter of nails	Length of nails	Designed speed	Motor	Dimension (L*W*H)	Weight
Z94-1C	0.9-1.6 mm	9-25mm	450PCS/min	1.5kw	1.5*1.2*1.1m	560kg
Z94-2C	1.2-2.8mm	16-50mm	300PCS/min	2.2kw	1.8*1.3*1.1m	950kg
Z94-3C	1.8-3.4mm	25-75mm	280PCS/min	3kw	2.0*1.3*1.3m	1200kg
Z94-4C	2.8-4.5mm	50-100mm	260PCS/min	4kw	2.2*1.6*1.4m	2000kg
Z94-5.5C	4.1-5.5mm	100-170mm	120PCS/min	5.5kw	2.5*1.8*1.6m	2500kg
Z94-6A	4.1-6.0mm	100-200mm	130PCS/min	11W	3.5*1.9*2m	6000kg
Z94-7C	4.1-10mm	150-330mm	100PCS/min	18.5kw	5*2.3*2.3m	11000kg

Picture of machines :
Process of nail :
5.Accessories of nail making machine :
Tungsten carbide Nail cutter grinder
NAIL POLISHING MACHINE
company services : 1. One year guarranty(except spare parts).
If quality problems happen within guarantee period, our company will repair for free.
2. Before delivery , we will 100% test all machines .
3. 24hours onine to give technical support .
canton fair :

---
