| US$700.00-2,500.00 | 1 Piece (MOQ) |
| MODEL | ZAY7020 | ZAY7032 | ZAY7040 | ZAY7045 | |
| Drilling capacity | 20mm | 32mm | 40mm | 45mm | |
| Face milling capacity | 63mm | 63mm | 80mm | 80mm | |
| End milling capacity | 20mm | 20mm | 32mm | 32mm | |
| Distance from spindle nose to table | 435mm | 450mm | 450mm | 450mm | |
| Min.distance from spindle axis to column | 181.5mm | 203.5mm | 203.5mm | 203.5mm | |
| Spindle travel | 85mm | 130mm | 130mm | 130mm | |
| Spindle taper | M.T.3 or R8 | M.T.3 or R8 | M.T.4 or R8 | M.T.4 or R8 | |
| Step of spindle speed | 12 | 12 | 12 | 12 | |
| Range of spindle speed | 50Hz | 100-2200 r.p.m | 80-2080 r.p.m | 80-2080 r.p.m | 80-2080 r.p.m |
| 60Hz | 120-2640 r.p.m | 100-2500 r.p.m | 100-2500 r.p.m | 100-2500 r.p.m | |
| Swivel angle of headstock (horizontally) | 360° | 360° | 360° | 360° | |
| Table size | 520×160mm | 800×240mm | 800×240mm | 800×240mm | |
| Forward and backward travel of table | 140mm | 175mm | 175mm | 175mm | |
| Left and right travel of table | 290mm | 500mm | 500mm | 500mm | |
| Motor Power | 0.55KW | 0.75KW | 1.1KW | 1.5KW | |
| Net weight/gross weight | 130kg/190kg | 280kg/330kg | 283kg/333kg | 285kg/335kg | |
| Packing size | 620×750×1000 mm | 1020×820×1160 mm | 1020×820×1160 mm | 1020×820×1160 mm | |
