2 Cavity Cavities Jar Bottles Width Mouth Water Bottle Oil Bottle Two Step Blow Blowing Moulding Molding Machinery

Product Description

Features
Apply 2L to 5L mineral water, carbonated drink, cooking oil, wine, medicine, cosmetics bottles etc
-Servo driving system, fast, stable and energy saving, optional servo clamping, preform loading and
stretching system
-Adopt pressurized plate to solve the mold swelling and big mold line problem
-Adpot human computer interface, PLC will automaticlly feedback fault point, easier maintain
-Adjustable lamps design makes the preform heating in the best situation
-Automatic oil adding device, can avoid the pollution risk of manual addin
Technique Parameter of blow molding machine:

ITEMS	Unit	TS-A1-120MM	TS-A2-80MM	TS-A2-120MM
Number of cavities	cavities	1	2	2
Max. volume	L	5	2	5
Neck size	mm	50-120	50-80	50-120
Max. Bottle dia.	mm	170	103	170
Max. Bottle height	mm	350	330	350
Theoretical output	bph	600-700	1500-1800	1000-1200
Rated power	kw	25	35	45
Power consumption	kw	12-15	15-20	20-25
Main machine size	m	2*1.4*2.2	2.7*1.8*2.1	3*1.9*2.2
Weight	kgs	1600	2500	3000

---
