| Motor standard | IEC |
| Motor type | 100LC |
| IE Efficiency class | IE3 |
| Rated power - P2 | 3 kW |
| Power (P2) required by pump | 3 kW |
| Mains frequency | 50 Hz |
| Rated voltage | 3 x 380-415D V |
| Rated current | 6.3 A |
| Starting current | 840-920 % |
| Cos phi - power factor | 0.87-0.82 |
| Rated speed | 2900-2920 rpm |
| Efficiency | IE3 87,1% |
| Motor efficiency at full load | 87.1 % |
| Motor efficiency at 3/4 load | 88.0 % |
| Motor efficiency at 1/2 load | 87.7 % |
| Number of poles | 2 |
| Enclosure class (IEC 34-5) | 55 Dust/Jetting |
| Insulation class (IEC 85) | F |
| Built-in motor protection | PTC |
| Motor No | 85U15510 |
