| US$103.60 | 1 Piece (MOQ) |
| Technical parameters | Index | |
| Input | Voltage input range | DC 0-1000V, See the physical wiring diagram |
| Current input | Shunt:0-75mV; Hall sensor:0-20mA,4-20mA,0-5V,0-10V and so on. | |
| Overload | 1.2 times rated (continuous); 2 times rated/1 second; | |
| Power consumption | Voltage: ≤0.2VA, current ≤0.1VA | |
| Accuracy class | Class 1 | |
| Function | Display | 8-bit segment LCD screen (LCD) |
| Communication Interface | RS485(two channels of RS485 can be chosed) | |
| Communication protocol | Modbus-RTU,DL/T 645-2007 | |
| Switch output | 2 Relay outputs, 2A/30VDC or 2A/250VAC | |
| Switch input | 2 dry contact inputs | |
| Pulse output | A second pulse output, an energy pulse output | |
| See the SYS->PLUS display in the meter menu settings. For example: The meter displays 100, which is 100imp/kWH | ||
| Power Supply | Voltage range | AC/DC 85-265V or DC24V(±10%) or DC48V(±10%) |
| Power consumption | ≤ 3W | |
| Power frequency withstand voltage | Power supply // Voltage input // Current input // Relay output and switch input // Communication interface / / Pulse output 3kV/1min Power supply // Relay output // Voltage input // Current input 3kV/1min Pulse output // Communication interface // Switch input 2kV/1min | |
| Impulse withstand voltage | ±6KV | |
| Average barrier-free working hours | ≥50000h | |
| Environment | Temperature | Normal operating temperature: -25 °C ~ +65 °C; Limit working temperature: -40 °C ~ +70 °C; Storage temperature: -40ºC~+80ºC |
| Humidity | ≤93%RH, no condensation, no corrosive gas | |
| Altitude | ≤2500m | |
