Roller Idler Special-Purpose Welding Machine Automatic Conveyor Roller Making Machine Conveyor Idler Roller Welding Machine

Product Description

Product use and scope of applicationThe machine adopts CO2 as the protective gas of welding or the protective welding method of using flux-cored wire CO2. The welding strength is high, the center is automatically adjusted, and the welding is at the same time. The pneumatic clamping can complete the hydraulic cylinder, fire fighting equipment, roller, etc. In particular, the control system based on the imported programmable controller (PLC) is adopted to replace the traditional relay logic control circuit to make the equipment reliable. The scope of application and work efficiency have been greatly improved.

Technical parameters

project	parameter
model	TH-160*2200
Machine tool center height	850mm
Welding workpiece length	200-2200mm
Welding workpiece diameter	Ф76-Ф159mm
welding current	60-350A(350KR)
floating voltage	45-55V(350KR)
rated capacity	50KVA(350KR)
shield gas flow rate	10-25L/min
Weldable workpiece length	200-2200mm
Welding rotation speed	0-10rpm/min
outline dimension	3800x500x1150
weight	1500Kg

---
