| Specifications | Parameters |
| Model | EGML28GMC-4G-220VAC |
| Ports | Up to 24 Gigabit Ports And 4 Fiber Ports with SFP Slot |
| RJ45 Port Connectors | 10/100Base TX or 10/100/1000BaseT Auto-negotiation Speed, Full/Half Duplex, MDI/MDI-X Auto-sensing |
| Fiber Port Connectors | 1000Base SX/LX/ZX/LHX(SFP Slot) |
| IEEE Standards | IEEE802.3-10BaseTIEEE802.3u-1000BaseTX/1000Base-FX IEEE802.3x-Flow ControlIEEE802.3z-1000BaseLX IEEE802.3ab-1000BaseTX IEEE802.1ab IEEE802.1D-Spanning Tree Protocol IEEE802.1w-Rapid Spanning Tree Protocol IEEE802.1Q -VLAN Tagging IEEE802.1p -Class of Service IEEE802.1X-Port Based Network Access Control |
| Network security | Supports user hierarchical management and password protection IEEE 802.1x certified/centralized MAC address authentication is supported RADIUS certification is supported Protected ports are supported MAC filtering is supported Support for IP-MAC-port binding |
| Features | support for IPV4/IPV6 management Static/default routes are supported, with a maximum of 128 entries ARP protocol is supported, with a maximum of 1024 entries VLAN support, up to 4096 VLAN, support port-based VLAN, support 802.1Q standard VLAN; Enriched Manage Functions Such as QoS, VLAN, IGMP Snooping/GMRP Support for STP/RSTP/MSTP Supports standards and extended ACLs Port mirroring is supported IEEE802.3X Flow Control, Back Pressure |
| Management | Management: by Web Browser Support Telnet remote management Support for SNMP network management |
| Power | <45W |
| Environment Limits | Extended Temp Models: -40 to 75˚C Storage Temperature: -40 to 85˚C Ambient Relative Humidity: 5 to 95% ( Non-condensing ) |
| Agency Approvals | EMI FCC Part 15 Subpart B Class AEN 55022 Class A EMS : IEC(EN)61000-4-2(ESD) : ±8kV IEC(EN)61000-4-3(RS) : 10V/m(801000MHz) IEC(EN)61000-4-4(EFT) : power: ±4kV; data : ±2kV IEC(EN)61000-4-5(Surge) : power : ±4kV CM/±2kV DM ; data:±2kV IEC(EN)61000-4-6 : 3V(10kHz150kHz),10V(150kHz80MHz) IEC(EN)61000-4-16 : 30V cont. 300V,1s IEC(EN )61000-4-8 Shock IEC 60068-2-27 Freefall IEC 60068-2-32 VibrationIEC 60068-2-6 |
| Properties | Layer-2 Switching Processing Type: store-and-forward Priority Queues: 4 IGMP Groups: 64 Max. Available VLANs: 256 VLAN ID Range: 1~4094 MAC Address: 16k MAC Address Table |
| Power Inputs | AC110240V/5060Hz |
| Physical Characteristics | Dimensions: 440 × 44.5 × 337 mm (W×H×D) Level of Protection: IP40 Installation: DIN-rail or panel mounting |
| LED Indicators | Power, ACT/LINK |
| Protection | IP40 |
| Certification | CEFCC |
| Environmental | RoHS, WEEE |
| MTBF | 380,000 hours |
| Warranty | 5 Years |
