International Standard Pet Flakes Washing Line Plant

Product Description

International standard PET flakes washing Line Plant

Product Description
1,This PET recycling machine can easily wash and recycle waste PET bottle flakes ,which includes PE/PP labels, PVC labels, paper labels, HDPE cups, glue, mud, beverage leftover, oil, and scrap iron..
2, PET recycling machine at the end of the washing line so that the completely dry flakes can be collected and packed directly after being washed.
3, the whole PET recycling machine can be designed on the basis of how dirty the flakes are, and make sure of the quality of the final products..
4, Coordinating the production line with follow programmed work (granulating system), and it will make waste and dirty PET bottles to be the PET granule material and in order to producing new PET bottles. The material from this equipment can be put into the granulating machine directly.
5, we can supply PET recycling machine with capacity from 100kg/h to 2500kg/h..'
And you are welcomed to my factory to see the PET recycling machine .We design and produce all the PET recycling machine by ourself.
The whole equipment includes parts of PET recycling machine:

NO	Item	Quantity	Remark
1	Bale breaker	1 set	This part can be added according to the customers.
2	Belt conveyer	1 set	Including the metal detector.
3	Label remover	1 set	Label removing efficiency: uncompressed bottles more than 98%,compressed more than 90% Cap removing efficiency: more than 90%
4	Manual select and separate working table	1 set
5	Belt conveyer	1 set
6	Crusher	1 set	With water, the material of the blade adopt SKD-II or 9CrSi
7	Screw feeder	1 set
8	Friction washer	1 set
9	Twin screw floating washer	1 set
10	Screw feeder	1 set
11	Hot steam washer	1 set
12	Screw feeder	1 set
13	Friction washer	1 set
14	Twin screw floating washer	1 set
15	Dewatering machine	1 set
16	Drying system and Storage hopper	1 set
17	Electrical control cabinet	1 set	Adopts Siemens and DELIXI as main component.
Annotation: 1, some equipment can be increased or decreased as the dirty degree of the bottles and the capacity. 2, the material can be made by the customers' requirement. Normal are carbon steel or stainless steel.

New Generation Recycled PET Bottle Flake Washing Line

---
