UPVC Door and Window Profile Machine

Product Description

250mm PVC Ceiling Panel Machine Door Window Profiles

KBL series plastic profile extrusion line is mainly used for producing plastic profiles, such as PVC door and window profile, imitatednarbled profiles, WPC profiles, wide door profiles, window sills and multihole conduit pipes(for example the four holes, six holes, seven holds, nine holds conduit pipes). According to the different cross section of profiles and the moulds, a different model of twin-screw extruder will be chosen, mating corresponding the vacuum forming table, haul off machine, cutter and stacker. All og them consist of a particular plastic profileextrusion line. The capacity of extruder could be selected from 60kg/h up yo 700kg/h. Haul off machine adopts the unipuefluctuation technology, which remains the stable work, good reliability and strong traction. The vacuum forming table adopts increased vortex cooling system, which is easier for cooling and forming so that can meet the requirement of the high speed extrusion. The traction speed of cutting machine keeps synchronization with the haul off machine, which adopts PLC control, reasonable design, stable operation, automatic fixed length cutting and with dust collection device. According to different mould sizes, the vacuum forming table can be chosen as 4 meters, 6 meters, 8 meters, 11 meters, etc.
Technical parameter of pvc ceiling nigeria/machine to making pvc ceiling

Model	YF180	YF240	YF300	YF400	YF600	YF800	YF1000	YF1200
Max. size of product	180	240	300	400	600	800	1000	1200
Extruder model	65/132	65/132	80/156	80/156	80/156	80/156	92/188	92/188
Motor power(kw)	37	37	55	55	55	55	110	132
Max. output(kg/h)	200	200	320	320	320	320	500	550
Dosage of cooling water	7	8	8	10	12	14	16	18
Dosage of compressed air	0.5	0.5	0.5	0.5	0.6	0.6	0.8	1

---
