Specification of FOTON Ambulance | |||
| Item | Specification | Item | Specification |
| General | |||
| Truck Name | Ambulance | Overall Dimension (mm) | 5380×1920×2505 |
| Truck Brand | FOTON | Gross / Curb Weight (kg) | 3400 / 2060 |
| Truck Model | * | Approach / Departure Angle (°) | 16 / 17 |
| Max. Speed (km/h) | 145 | Front / Rear Overhang (mm) | 1190 / 1080 |
| Chassis | |||
| Chassis Brand | FOTON | Chassis Model | * |
| Wheel Base (mm) | 3100 | Leaf Spring | -/3+1 |
| Traction System | 4 x 2 | Quantity of Axles | 2 |
| Rated Passenger | 5~8 | Front / Rear Axle Load (kg) | 1630/1770 |
| Transmission | 5 speed, manual | Front / Rear Wheel Tread (mm) | 1655 / 1650 |
| Tyre Model | 195R15C | Quantity of Tyre | 4 |
| Engine (Motor) | |||
| Brand | FOTON | Type of Fuel | Diesel |
| Model | ISF2.8s4129P | Displacement (ml) | 2780 |
| Max. Power (Hp) | 130 | Emission Standard | Euro 5 |
| Standard Configuration | |||
| 1) Control plate of siren and alarm lamp mounted in driver's cab | 1 set | ||
| 2) Adjustable volume alarm apparatus | 1 set | ||
| 3) Red flashing alarm light bar 100w mounted on the front roof of vehicle and with 3 pieces lights | 4 pcs | ||
| 4) Red flashing alarm lamps four sides of vehicle outside roof | 10 pcs | ||
| 5) Composite material interior decoration in patient compartment | 1 set | ||
| 6) Medicine cabinet | 1 set | ||
| 7) Oxygen cylinders 10L | 1 pc | ||
| 8) Ultraviolet radiation disinfector light | 1 pc | ||
| 9) Dirt bucket | 1 pc | ||
| 10) Individual seat | 3 pcs | ||
| 11) Long bench one piece (suitable for 3 people) with safe belts, mounted in right side of patient's compartment | 1 pc | ||
| 12) A foldable doctor seat (with safe belt) mounted to floor near to compartment wall | 1 pc | ||
| 13) Partition wall between driver's cab and patient's compartment, a glass window in wall to make observation | 1 set | ||
| 14) 12V light lamp | 2 pcs | ||
| 15) Intelligent inverted power supply system (12-220V) 500W | 1 set | ||
| 16) 220V wall outlet | 1 set | ||
| 17) Interior medical floor | 1 set | ||
| 18) Cross mark outside marking | 1 set | ||
| 19) The original air conditioning is installed in driver's cab and in patient's compartment | 2 sets | ||
| 20) Exhaust system is installed on patient's compartment roof | 1 set | ||
| 21) Multi-functional interior roof in patient's compartment, with handrail, transfusion hanging bracket | 1 set | ||
| 22) Portable and foldable stretcher | 1 set | ||
| 23) Automatic loading-and-unloading stretcher | 1 pc | ||
| 24) Hand-free intercom system between driver's cab and patient's compartment | 1 pc | ||
| 25) 100W loud speaker | 1 pc | ||
| 26) Oxygen reducing valve | 1 set | ||
| 27) Fire extinguisher | 1 set | ||
| NOTE: | |||
| 1. Any part can be customized depending on customers' demand. | |||
| 2. 12 months whole vehicle warranty | |||
| 3. We could support you original spare parts. Besides, we can give assistance in the following days by email or telephone. If necessary, our outwork engineer could go for technical assistance. | |||
| 4. MOQ: 1 unit | |||
