Machine parameters MKL-650T1 MKL-650T11 MKL-650Q
|
Product application range
| Less than 150(diagonal)
| Less than 120(diagonal)
| Less than 200(diagonal) greater than 12(thickness)
|
Workpiece material
| Steel, cast iron, ceramics, copper, aluminum, cemented carbide, magnetic materials (grinding wheel optional according to the material)
|
Spacing between two grinding wheels
| 80
|
Spindle speed
| Frequency conversion speed regulation, can achieve two spindle machining at different speeds
|
Workpiece autobiographical speed
| There is no
| 100r/min
|
Turntable feed speed
| 3s/ per piece
| 5s/ per piece
|
|
Grinding wheel Specifications
| From 650 x 250 x 50
| From 650 x 250 x 50
| From 650 x 250 x 50
|
Main motor power
| 15(KW)×2
|
Main engine form factor
| 1800(L) x 1200(W) x 2300(H)
|
Weight of the engine
| 5500( kg)
|
Machining accuracy and beat (mm)
|
Precision and beat
| MKL-650T1
| MKL-650T11
| MKL-650Q
|
Job instance
| Overall dimensions
| 120(diagonally) x 12(thick)
| 55(diameter) x 7(thickness)
| 180(diagonally) x 22(thickness)
|
| Grinding allowance
| 0.15
| 0.08
| 0.15
|
Parallelism
| Less than 0.02
| Less than 0.003
| Less than 0.005
|
Flatness
| Less than 0.01
| Less than 0.002
| Less than 0.003
|
Size control
| 0.01
| 0.005
| 0.006
|
Roughness
| 0.8 Ra
| 0.4 Ra
| 0.4 Ra
|
Loop beat
| 3-5 seconds per piece
| About 5 seconds for one piece
| A piece in 40-50 seconds
|
