Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
| PPC905AE101 3BHE014070R0101 |
• Only qualified personnel should carry out repairs. • The agreed warranty applies. • Before carrying out any cleaning or maintenance operations, disconnect the equipment from the electrical supply. • Clean the display and surrounding front cover with a soft cloth and mild detergent. • Replacing the battery incorrectly may result in explosion. Only use batteries recommended by the supplier. Dismantling and Scrapping • The operator panel or parts thereof shall be recycled according to local regulations. • The following components contain substances that might be hazardous to health and the environment: lithium battery, electrolytic capacitor and display. 3BSE043446R501 13 Section 3 Installation Space Requirements • Installation plate thickness: 1.5 - 9.0 mm (0.06 - 0.35 inch) • Space requirements when installing the operator panel: The openings on the enclosure are for air convection. Do not cover these openings. 50 mm 154 mm 219 mm (2.0 inch) 50 mm (2.0 inch) 100 mm (4.0 inch) 100 mm (4.0 inch) 100 mm (4.0 inch) 56 mm (2.20 inch) (8.62 inch) (6.06 inch) Installation Process Section 3 Installation 14 3BSE043446R501 Installation Process 1. Unpack and check the delivery. If damage is found, notify the supplier. 2. Place the panel cut out where the operator panel is to be situated, draw along the outer sides of the holes and cut according to the markings. Place the operator panel on a stable surface during installation. Dropping it or letting it fall may cause damage. x 4 Panel cut out 188.5 x 137.5 mm (7.42 x 5.41 inch) Section 3 Installation Installation Process 3BSE043446R501 15 3. Secure the operator panel in position, using all the fastening holes and the provided brackets and screws: 4. Connect the cables in the specified order. Ensure that the operator panel and the controller system have the same electrical grounding (reference voltage level), otherwise errors in communication may occur. Use an M5 screw and a grounding conductor (as short as possible) with a cross-section of minimum 2.5 mm2. - Use only shielded communication cables. - Separate high voltage cables from signal and supply cables. - The operator panel must be brought to ambient temperature before it is started up. If condensation forms, ensure that the operator panel is dry before connecting it to the power outlet. - Ensure that the voltage and polarity of the power source is correct. x 4 0.5 - 1.0 Nm A B C D Mode Switches Section 3 Installation 16 3BSE043446R501 5. Carefully remove the laminated film over the operator panel display, to avoid static electricity that could damage the panel. Mode Switches All mode switches must be in OFF position during operator panel use. The mode switches should not be touched unless by qualified personnel. The operator panel has four mode switches (DIP switches) located on the back of the operator panel.
>>
