Marine Fender Boat Fender Rubber Fender for Dock

Product Description

Marine Rubber Boats Fender Dock Fender
Rubber Fender
Marine rubber fenders have been widely used for berthing by ship to ship or ship to dock, such as marine pneumatic rubber fender, cylindrical type rubber fender, super cell rubber and cone type rubber fender etc.
CCS, BV, LR, GL, DNV, NK, ABS and RINA certification.
Sizes: Dia1M*2M, Dia1.2M*2M, Dia2M*2.5M, Dia2.5M*3, Dia2.5M*5.5M Dia 3.3*5M, Max Dia3.5M*8M, etc.
Feature:
1. Anti-explosion.
2. Wholely wrapped.
3. Anti-aging.
4. Thick material, 18layers, 19layers, 20layers, 21layers, 22layers, etc.
Description:
1. Inner: Rubber tube.
2. Middium layer: Multi-layer of rubber-dipped Nylon cord fabric.
3. Material: Natual rubber, anti-aging. Multi layer of rubber-dipped tyre fabric.
4. Outer: Tyre-chain net.
5. Tyre: Air tyre, car tyre.
6. Chain: Hot galvanized.
7. Flange: Hot galvanized or stainless steel.
8. Shackle: Hot galvanized.
9. Valve: Copper.
10. Working pressure: 0.05Mpa, 0.5Bar.
11. Testing pressure: 0.15Mpa, 1.5Bar.
Warranty: 12 months.
Life-span: 8 years.
Marine Rubber Fender Specification

specification Φ×L	Initial pressure inside	The compression is 60%		Body weight
		Counterforce	Energy absorption
mm×mm	Mpa	(KN)	KN.m	(kg)
500×1000	0.05	64	6	25
800×1500	0.05	156	19	57
1000×1500	0.05	182	32	68
1000×2000	0.05	257	45	100
1200×2000	0.05	297	63	120
1200×3000	0.05	410	87	160
1500×3000	0.05	579	153	315
2000×3000	0.05	776	273	518
2000×3500	0.05	875	308	590
2500×4000	0.05	1381	663	1050
3000×5000	0.05	2000	1050	1880
3000×6000	0.05	2488	1312	2160
3300×6500	0.05	3015	1814	2700

Any need of marine used fender please feel free to contact us!

---
