Chicken Duck Cattle Sheep Pellet Mill Poultry Animal Feed Pellet Machine

Product Description

Scope of usage of animal feed pellet machine:
animal feed pellet making machine is widely used in large, medium, and small aquaculture, grain feed processing plants, livestock farms, poultry farms, individual farmers and small and medium-sized farms, and farmers, or large, medium, and small feed processing plants. This animal feed pellet machine can make diferent kinds of pellets with diameters of 2-10mm.
Uses and features of animal feed pellet machine:
1. This animal feed pellet machine is mainly suitable for the processing of rabbits, fish, ducks, chickens, shrimps, pigs, deer, cattle, sheep, and industrial pellets. animal feed pellet making machine is widely used in industry, plastic pellets, organic fertilizer pellets, wood pellets, etc(fish food pellet maker).
2. Corn does not need to be crushed and can be added directly. The granular feed processed by this machine has a smooth surface and moderate hardness. The temperature rises during the processing and can better maintain the nutrients in the raw materials. (Note: Corn is added without crushing, and the granular composition is not as uniform as possible.)
3. The particles are uniform in composition and neat in shape. The pore size of the particles can be divided into ∮3, ∮4, ∮5, ∮6, ∮7, ∮8, etc. When ordering, users can choose according to the needs of different growth periods of the farmed animals.
4. Through squeezing, it can kill common pathogenic microorganisms and parasites, and can prevent the occurrence of some diseases. Due to the low moisture content of the pellet feed, it is easy to store and can be kept in the original state for a long time in the water, which greatly improves the utilization rate of the feed(fish food pellet maker).

Technical information of animal feed pellet machine:

Model	Power puissance	Capacity(feed)(kg/h)	Capacity(fuel)(kg/h)	Weight(kg)	Size(mm)
WSKL-125	2.2kw-3kw	75-100	40-60	75kg	650*300*600mm
WSKL-150	3kw	90-120	70-80	95kg	750*400*820mm
WSKL-200	7.5kw	200-300	100-150	110kg	900*400*750mm
WSKL-230	11kw	300-400	200-300	150kg	1180*580*880mm
WSKL-260	15kw	400-600	300-400	135kg	1200*500*1070mm
WSKL-300	22kw	600-800	500-600	220kg	1250*520*1070mm
WSKL-360	22kw	800-900	700-800	350kg	1270*520*1070mm
WSKL-400	30kw	1000-1200	800-1000	600kg	1470*500*1150mm

Features of animal feed pellet machine:
1. After many times of practice, the layout of the pressing wheel is reasonable, the pressing area is increased as much as possible, and the production efficiency is improved.
2. The top wire is used to control the gap between the grinding disc and the pressing wheel to ensure the pressing effect.
3. Equipped with a variety of hole-shaped abrasives to meet the actual needs of animals in different growth periods(fish feed pellet machine).
4. Animal feed pellet machine has a simple structure and is suitable for a wide range of materials. Concentrate feed, grass powder, and corn kernels can be mixed with a small amount of water evenly. The produced feed pellets have high hardness, smooth surface, and mature surface, which can kill various parasite eggs and other pathogenic microorganisms, and have a faint fragrance.
Precautions in the use of animal feed pellet machine:
1. Add oil to the oil mirror position first. Adjust the screw of the pressing wheel until the grinding disc and the pressing wheel are in contact, and the hand can not turn it.
2. Power on the wiring, check whether the rotation of the motor is correct, and run in the direction indicated by the arrow. If it is not correct, adjust any two wires. After the adjustment is completed, start the machine to check the rotation of the pressure roller again, and adjust it again.
3. Preparation of abrasives and grinding machines.
4. After the processing is completed, if it is not used for a long time, press the abrasive material into the grinding disc, and then loosen the screw of the pressing wheel to make the roller in a free state.
5. There must be no foreign objects such as stones, iron blocks, screws, etc. in the raw materials, so as not to damage the animal feed pellet making machine.
Instructions of animal feed pellet machine:
1. Start the machine only after adding hypoid gear oil to the gearbox.
2. Install the pellet machine smoothly, whether the steering meets the requirements, whether the screws in each part are loose, loosen the adjustment screw on the roller shaft seat, so that the feed machine is in a no-load state, and it can be put into use after it starts and runs normally.
3. Before using the new machine for the first time, take 10 kg of sawdust (or grass meal) vegetable oil or waste machine oil, mix well, and turn the adjustment screw. Make the speed of the two rollers the same, gradually add the oil feed, and continue to tighten the adjusting screw to slowly produce pellets.
The extruded pellets are repeatedly rolled to make the die hole smooth and smooth, and then slowly add the required processing mixture For feed processing, if the die hole resistance is large, the output is low or the material is not discharged, the template can be repeatedly ground according to the above method to make the die hole smooth and lubricated before processing.
4. In the feed processing, if there is more refined fiber, about 5% of the water should be added. If there are more refined materials in the mixed feed, the amount of water added can be reduced as appropriate. After processing, add a little oil that has been mixed with edible oil in advance, which is beneficial to the next time. Turn on the machine to prevent the feed from drying in the hole after the animal feed pellet machine stops.
5. After processing, loosen the adjustment screw to make the rollers in a free state. After the machine stops, remove the remaining material deposits in the upper and lower bins, especially the remaining material at the bottom of the plate to avoid damage to the bearing(pellet press machine).

---
