| Outside Dimension (mm) | 7000×5900×3400 | |
| Inside Dimension(mm) | 6900×3900×2650 | |
| Front Door(mm) | 3000×2600(W*H) | |
| Service door(mm) | 800×2000(W*H) | |
| Total Power | 6.5kw | |
| Cabin system | Front door | 3 folded sheet metal formed door |
| Wall panel | 50mm EPS sandwich panel, steel sheet thickness: 0.426mm (Rock-wool panel for option) | |
| Ceiling panel | Galvanized steel sheet | |
| Basement | 30mm depth construction galvanized basement, two rows galvanized grids and three rows checkered plates. | |
| Ramps | Two pieces 2000*520mm ramps | |
| Door glass | 5mm tempered glass | |
| Air make-up system | Air inlet fan system | One set direct drive 5.5KW turbo fan |
| Exhausted fan system | For option | |
| Air inlet capacity | 22000m3/h | |
| Exhausted ducting | Four meters straight galvanized ducting and one 135 degrees elbow | |
| Purification system | Pre-filter | G3 grade |
| Ceiling filter | 600G filter EU5 / F5 | |
| Floor filter | Fiberglass filter | |
| Exhausted filter | for option | |
| Heating system | Heat Exchanger | SUS 304 stainless heating exchanger |
| Heating burner | Riello G20 diesel oil burner (gas burner for option) | |
| Heating productivity | 20000Kcal/hour | |
| Spray to baking switch | Pneumatic damper | |
| Chimney ducting | 4 meters chimney and one chimney elbow | |
| heating temperature | Maximum 80ºC | |
| fuel consumption | 6-8L/vehicle | |
| Lighting system | Ceiling lighting | 8 Units, each 4 * 16.5W LED lamps. |
| Side lighting | For option | |
| Illumination | 900LUX | |
| Control system | Switch controlling system | Spraying & baking switch, lighting switch, temperature controlling switch, emergency stop, breakdown alarm, failure alarm, pressure gauge |
