Basic Info.
Transport Package
Steel Pallet, Wooden Box,
Production Capacity
60sets/Month
Product Description
Z94 SERIES HIGH SPEED LOW NOISE ,AUTOMATIC NAIL MAKING MACHINE Function:
1. This nail making machine adopts piston structure to ensure the high working speed, low noise and less chance of impact characteristics.
2. Especially it can make excellent quality of common nail , coil nail and other special-shaped nail .
Specification :
| Model | Diameter of nails | Length of nails | Designed speed | Motor | Dimension (L*W*H) | Weight |
| Z94-1C | 0.9-1.6 mm | 9-25mm | 450PCS/min | 1.5kw | 1.5*1.2*1.1m | 560kg |
| Z94-2C | 1.2-2.8mm | 16-50mm | 300PCS/min | 2.2kw | 1.8*1.3*1.1m | 950kg |
| Z94-3C | 1.8-3.4mm | 25-75mm | 280PCS/min | 3kw | 2.0*1.3*1.3m | 1200kg |
| Z94-4C | 2.8-4.5mm | 50-100mm | 260PCS/min | 4kw | 2.2*1.6*1.4m | 2000kg |
| Z94-5.5C | 4.1-5.5mm | 100-170mm | 120PCS/min | 5.5kw | 2.5*1.8*1.6m | 2500kg |
| Z94-6A | 4.1-6.0mm | 100-200mm | 130PCS/min | 11W | 3.5*1.9*2m | 6000kg |
| Z94-7C | 4.1-10mm | 150-330mm | 100PCS/min | 18.5kw | 5*2.3*2.3m | 11000kg |
Picture of machines :
Process of nail :
5.Accessories of nail making machine :
Tungsten carbide Nail cutter grinder
NAIL POLISHING MACHINE
company services : 1. One year guarranty(except spare parts).
If quality problems happen within guarantee period, our company will repair for free.
2. Before delivery , we will 100% test all machines .
3. 24hours onine to give technical support .
canton fair :
>>
