Bonnet for Style FC&FL&Fls Manual Gate Valve 410

Product Description

Repair Kit for the Type FC Manual Slab Gate Valve
Our cutting-edge kit is perfectly compatible with the Cameron FC/FLS gate valve, providing seamless integration and superior functionality.
1. Benefit from a fully and internally flushed bore combined with a robust forged construction, ensuring maximum durability and efficiency even in the toughest environments.
2. Experience the reliability of metal-to-metal sealing that delivers exceptional sealing performance, preventing leakage and enhancing operational integrity.
3. The innovative slab gate design offers precision control and robust performance, making it an essential component for optimal valve operation.
4. Appreciate the design simplicity, which allows for easy maintenance and minimal downtime, effectively saving time and resources.
5. Enjoy the advantage of bidirectional sealing, providing exceptional sealing capability in both directions for versatile application.
The FC/FLS gate valve is a versatile and reliable choice, typically utilized at choke and kill manifolds, wellheads, and X-Mass trees, making it a critical component in oil and gas operations.

API6A Gate Valve - Valve Body (Manual or Hydraulic) Size: 1-13/16" - 7-1/16" Rated Working Pressure: 2000PSI, 3000PSI, 5000PSI, 10000PSI, 15000PSI Material: AISI4130 Integral Forged, Stainless Steel or Customized Outlets: Flange, Thread, or Clamp Material Class: AA, BB, CC, DD, EE, FF, HH L-V, PSL1-PSL4, PR1-PR2

API6A FC Type Gate Valve - Gate Size: 1-13/16" - 7-1/16" Working Pressure: 2000PSI, 3000PSI, 5000PSI, 10000PSI, 15000PSI Material: AISI410 +Tungsten Carbide Hardfacing or Customized This valve body can be used in both DD and EE trim valves.

API6A FC Type Gate Valve - Bonnet Size: 1-13/16" - 7-1/16" Working Pressure: 2000PSI, 3000PSI, 5000PSI, 10000PSI, 15000PSI Material: AISI4130 or Customized This Bonnet can be used in both DD and EE trim valves.

API6A FC Type Gate Valve - Handwheel Valve Size: 1-13/16" - 7-1/16" Valve Working Pressure: 2000PSI, 3000PSI, 5000PSI, 10000PSI, 15000PSI Material: 1045 or Customized

API6A FC Type Gate Valve - Stem Adapter Size: 1-13/16" - 7-1/16" Working Pressure: 2000PSI, 3000PSI, 5000PSI, 10000PSI, 15000PSI Material: AISI4130, stainless steel or Customized This Stem Adapter can be used in both DD and EE trim valves.

API6A FC Type Gate Valve - Stem Packing Size: 1-13/16" - 7-1/16" Working Pressure: 2000PSI, 3000PSI, 5000PSI, 10000PSI, 15000PSI Material: NBR+F4 or Customized This Stem Packing can be used in both DD and EE trim valves.

API6A FC Type Gate Valve - Retainer Plate Size: 1-13/16" - 7-1/16" Working Pressure: 2000PSI, 3000PSI, 5000PSI, 10000PSI, 15000PSI Material: 1020 or Customized This Retainer Plate can be used in both DD and EE trim valves.

API6A FC Type Gate Valve - Gate Guide Size: 1-13/16" - 7-1/16" Working Pressure: 2000PSI, 3000PSI, 5000PSI, 10000PSI, 15000PSI Material: 1020, stainless steel or Customized This Gate Guide can be used in both DD and EE trim valves.

Product Paramenters

Working pressure(psi)	2000psi to 20000psi
Material class	AA,BB,CC,DD,EE,FF
PSL	PSL1,PSL2,PSL3,PSL4
PR	PR1
Bore size	1-13/16" to 7-1/16"

Product display



Product packaging

---
