Industrial Algae Fermentor Bioreactor Fermentation 200L Chemical & Machinery

Product Description

Product Description this fermentation tank is ideal system for production of bacteria, yeast, enzyme,and fungi ,etc in aerobic and vaccines cultures.This series of products suits for various kinds of microbiology lab, pilot and industrial scale fermentation. User can choose appreciate model according to Client s detail requirement. We have model from 1L---30000L. Feature 1. It can set the upper and lower limits of temperature, speed, Ph value, DO value, and has the function of over-limit alarm;2. With super liquid level alarm and automatic replenishment function, with super foam level alarm and automatic addition of defoamer function;3. All alarm accidents can be recorded and consulted;4. Speed, temperature, Ph value, DO value, etc. can be set to automatic or off;5. The parameters of the medium temperature, stirring speed, Ph, DO and other parameters in the tank can be controlled by setting the curve according to the process requirements;6. Each parameter has PID adjustment process display, such as set value, real-time value, PID set value, upper and lower limit value, curve display, manual/automatic switching, online setting, etc.;7. The historical data and curves of various parameters can be saved for many years, and the real-time curve can be restored as it is when the power is turned off and restarted;8. Friendly man-machine interface, can switch more than a dozen monitoring screens;9. It has the function of feeding and measuring; regular quantitative feeding;10. The system has a variety of related controls: the related control of speed and dissolved oxygen, the related control of feeding and dissolved oxygen, the related control of feeding and pH value, etc.;11. The system has real-time display, data recording and data analysis of the running process12. The parameters of each detection and control loop can be manually set and corrected online on the screen, and the temperature, DO, PH sensors can be adjusted and adjusted, and the flow rate of each peristaltic pump can be calibrated; the operation has a password protection function, and the password is divided into operation. Member and administrator level passwords;13. Automatically record the start-up time, shutdown time of the fermentation tank, the number of power outages during automaticoperation, the outage time, the call time, etc.;14. The software system has the ability of self-adaptation and self-diagnosis;

Technical parameter

Item name	Multiple Stainless-steel Bioreactor
Multiple quantity	1-20units combination
Volume	10L-10000L volume optional
Configuration	Temperature, pH, dissolved oxygen, speed, foam, replenishment, air flow(manual), tank pressure (manual)
Control system	LBR-A, B, C, D, H biological engineer control
Application	Suitable for fermentation experiment research from laboratory to production process, and can also be used for small-scale production

Detailed Photos

Our Workshop
Our customer

---
