| ENGINE | |
| Model | Kubota Engine |
| Cylinders | 3 |
| Bore/Stroke | 80×90mm |
| Displacement | 1.357L |
| Fuel injection | direct |
| Fuel injection pump | Mechanical |
| Fuel | Diesel |
| Fuel filter | Full flow |
| Cooling | water-cooling |
| Horsepower Net | 15.5kw @2400rpm |
| Maximum torque Net | 71N.m @1680rpm |
| BOOM/ARM | |
| BOOM | |
| Swing | 60° left / 45° right |
| Length | 1805mm |
| Boom weight | 69kg |
| Arm | |
| Length | 1150mm |
| Arm weight | 35kg |
| UNDERCARRIAGE | |
| Number of rollers | |
| Top, each track | 1 |
| Bottom, each track | 3 |
| Gradability | 58%(30°) |
| HYDRAULICS | |
| Pumps(2) | Gear pump |
| Capacity-Maximun | 2×21.6L/min |
| System relief pressure-standard | 18MPa |
| Pilot control hydraulic system-pump(1) | Gear pump |
| Maximun capacity | 7.2L/min |
| Relief pressure | 3MPa |
| Control valves- | |
| 8 function multiple control vavle | |
| Pump#1 for right travel and swing and boom swing and arm | |
| Pump#2 for left travel and boom and bucket and dozzer | |
| Pump#3 for pilot valve | |
| Swing- | |
| motor(1) | cycloid motor |
| Speed | 0-10rpm |
| Brake | Hydraulically released |
| Tail swing radius | 1130mm |
| Tail swing overhang | |
| Travel- | |
| motor(2) | cycloid motor |
| Final drive | Gear reduction |
| Travel speed - | Forward/reverse |
| Low | 2.0km/h |
| High | 0km/h |
| HUDRAULIC CYLINDERS | |
| Boom cylinder(1) | |
| Bore diameter | 63mm |
| Rod diameter | 35mm |
| Stroke | 410mm |
| Arm cylinder(1) | |
| Bore diameter | 63mm |
| Rod diameter | 35mm |
| Stroke | 430mm |
| Bucket cylinder(1) | |
| Bore diameter | 55mm |
| Rod diameter | 32mm |
| Stroke | 300mm |
| ELECTRICAL | |
| Voltage | 12 volts |
| Alternator | 25 amp |
| Batteries(1) 12V | Heavy-duty |
| SERVICE CAPACITIES | |
| Hydraulic tank | |
| Refill capacity | 25L |
| Total system | 32L |
| Engine | |
| w/filler change | 3.5L |
| Fuel | 18L |
| Radiator | 3.5L |
| OPERATING WEIGHT | |
| With 75kg operator,44kg bucket, | |
| full fuel and standard equipment | 1700kg |
| Ground pressure | 33kpa |
