4G Wifi SD Card Mobile DVR Kit People Counter RS232/RS485 Port Bus Passenger Counting System

Product Details

Product Description

Product Description
4G Wifi SD Card Mobile DVR Kit People Counter RS232/RS485 Port Bus Passenger Counting System
The Video-Counting Passenger Counter (VPC) is an electronic device available for installation on transit vehicles including buses which accurately records boarding and alighting data.This technology can improve the accuracy and reliability of tracking.We are specializing in R&D ,production,sales of vehicle video monitoring system,3G/4G/GPS monitoring kits, intellectual bus dispatcher`s monitoring system ,video streaming people counter. Our products refers to SD/ HDD mobile DVR,3G or 4G remote control monitoring dvr,vehicle multi-media Ads function,Car camera,Supporting PTZ control realized by local ad client software.They are widely used in all kinds of vehicle,Such as:Bus passengers counting,logistics vehicle,law enforcement cars,the ambulance and so on.
IP: This is the IP address to login the counter, default IP: 192.168.0.192
Port: This is the port to login the counter, default port:6008
Username: this is the user name to login, no need to input user name when you config the data
Password:this is the password to login, no need to input password when you config the data
Set Time: The time is for the counter system, could set it according to the actual time(MDVR with counter kit no need set the time）
Reset CH1：CH1 Clear data
Reset CH2：CH2 Clear data
Update Camera Param:Update the parameters according to the number on the camera
Refresh Image: Refresh the background
Save Image:Save the background image for the first time (When the installation environment changes, also need to save the background image)
Video:for Development and debugging use
Download Record: Download the records.
Erase Record: clear all the records
txt/excel:the file format of the downloaded record file
Parameter Set:Set the parameter
Restart Device:Restart the device
Restore Factory Set :Reset the device to factory settings
Update System:Firmware update

---
