Explosion-Proof Internal Mixer Oxygen Analyzer

Product Description

Explosion-proof internal mixer oxygen analyzer
Brief description:
When the explosion-proof internal mixer oxygen analyzer is running at high speed, static sparks will be generated. If the materials inside contain flammable and volatile gases such as alcohols, benzenes, esters, etc., there will be a safety hazard of explosion.
Introduction:
When the explosion-proof internal mixer oxygen analyzer is running at high speed, static sparks will be generated. If the materials inside contain flammable and volatile gases such as alcohols, benzenes, esters, etc., there will be a safety hazard of explosion.
At present, most of the solutions in the industry adopt nitrogen replacement. The length of replacement time is based on production experience, the second is to look at the nitrogen pressure value, and the third is to continuously perform nitrogen protection; however, the above solutions are not scientific, and cannot accurately feedback the value of oxygen in the centrifuge, or cause a waste of nitrogen resources, resulting in frequent centrifuge explosion accidents.
In view of the above situation, our company adopts pre-stage sampling pretreatment + on-site numerical display + automatic nitrogen filling/cutting off the centrifuge power supply, and can also pass 4-20mA signal according to the supporting needs.
Application field of explosion-proof internal mixer oxygen analyzer:
Enclosed centrifuge nitrogen filling protection system;
Nitrogen filling protection in various process processes;
Storage tank nitrogen filling protection system;
Product features:
1. Customized pretreatment: backflush, acid-base neutralization, organic matter removal, dewatering, cooling, drying, voltage stabilization, constant current, etc. of sample gas;
2.Safety: When the oxygen concentration value exceeds the first-level preset alarm value, the electromagnetic adjustment of nitrogen filling and replacement is automatically turned on until the value drops to a safe range; when it exceeds the second-level preset alarm value, the power supply is automatically cut off to stop the centrifuge from working;
3.Applicable explosion-proof area: intrinsically safe explosion-proof composite instrument, meeting the requirements of strict use areas;
4.Nitrogen flow control: equipped with a nitrogen control box, when the oxygen concentration value is within the safe range, it automatically cuts off the large flow of nitrogen to achieve a small flow of continuous supply to meet the micro-positive pressure in the centrifuge;
5.Module platform: The number of pretreatment levels and functions can be freely adjusted according to actual use. Wider adaptability;
6.Easy maintenance: one-button calibration/calibration, tool-free disassembly and maintenance, hot-swap replacement of sensor components;
7.Intelligent display: self-luminous OLED display, wide multi-angle observation;
Technical parameters:

Model	XMB-YW-200
Measurement range	0~25%VOL
Detection principle	fluorescence quenching, electrochemical detection accuracy: 0.1%VOL
Explosion-proof grade	ExdibIICT6Gb
Protection grade	IP67
Response time	T90<20S
Output	4-20mA, RS485, HART protocol Switch output: 4 groups (2 groups for use and 2 groups for standby) Rated voltage:DC24V
Acquisition	16-bit ADC digital-to-analog conversion

---
