High Accuracy China Factory Ck620A2 Precision CNC Lathe Small CNC Version 2024

Product Description

Product Description
China Factory High Accuracy CK620A2 Small Precision Gang Tooling CNC Lathe Machine
-CK620A2 is small high precision gang type cnc lathe
Features:
1. CK0620A2 has the characteristics of simple practical,easily operate, high accuracy processing.
2. Its can achieve the processing of complex parts, such as straight line,taper,arc and thread, especially suitable for batch production and processing of complex parts.
3. Equipped with center rest,can process slender shaft type workpieces, convenient as sliding headstock lathe. The functions of CNC system is integrity, easily operate.
4. Equipped with automatic feeder, achieve automatic production.

Product Parameters
CK620A2 Small High Precision Gang Type CNC Lathe

Power	Rated Voltage	Three-phase AC 380V
	Rated Frequency	50HZ
	Total Input Power	3.2kW
CNC system	BYSK	YZ190
	Minimum Set Unit	0.001mm
	X Axis Pulse Equivalent	0.0005mm
	Z Axis Pulse Equivalent	0.001mm
	Max Program Size	±9999.999
	Cutting Speed	1--4000mm/min
	X Axis Rapid Feed Speed	15000mm/min
	Z Axis Rapid Feed Speed	18000mm/min
Main Spindle	Max Bar Diamater	Φ20mm
	Main Spindle Through-hole Diameter	Φ21mm
	Max Rotate Diameter	Φ200mm
	Main Spindle Center Height from Ground	1000mm
	Main Spindle Speed	0-5000r/min
	Main Spindle Motor Power	2.2kW
Travel	X Axis Travel	300mm(Diameter)
	Z Axis Travel	200mm
	X Axis Servo Motor Power	0.4kW
	Z Axis Servo Motor Power	0.4kW
	Guide Rail Form	Linear Guide Rail

Gang Tooling System	T notch	6pcs
	10*10square+16*16square	2pcs+2pcs
	Φ16 Hole Cutter	2pcs
Cooling System	Cutting Oil Motor Power	0.12kW
	Cooling Box Capacity	30L
Lubrication System	Motor Power	35W
	Capacity	2L
Pneumatic System	Input Compressed Air Pressure	0.4--0.6Mpa
Lathe Size	Length*Width*Height	1120*990*1810
	Lathe Weight	700kg

CK0620A2 Configurations
Item	Specification	Origins
CNC System	YZ190	Baoyu BYSK
Main Spindle Motor	2.2kW Asynchronous Motor	Dedong
X Axis Motor	0.4kW Absolute Value Servo Motor	Inovance/DELTA+Lines
Z Axis Motor	0.4kW Absolute Value Servo Motor	Inovance/DELTA+Lines
X Axis Screw Rod	333*1605	Taiwan Joint Venture
Z Axis Screw Rod	400*2006	Taiwan Joint Venture
X Axis Guide Rail	HGH20	HIWIN/PMI/THK
Z Axis Guide Rail	HGH20	HIWIN/PMI/THK

Detailed Photos
Premium Body Materials
Cutting-Edge CNC Control SystemBaoyu bysk 190: Effortless operation with comprehensive functionality
The panel is designed for easy movement and swiveling, enhancing operability.
Sophisticated Inner Structure
Inner Structure Features:
High tool capacity withrapid tool exchange Mainly designed toprocess various ultra-slender components Thepower headsatisfies the requirements of turning andcomplex milling processes (thelivehead is optional). Optimized layout, compact dimensions,and minimal space requirement.

The CK1113 CNC Lathe is equipped with an oil film bar feeder, high-pressure oil pump, and oil mist machine, enhancing lathe performance and longevity.
Processed Product Display
Valuable Expert Recommendations
--For profiles with a maximum diameter of up to 7mm, we highly recommend our top models: B07 and CK1107. The B07 model boasts an advanced dual spindle design, while the CK1107 model features a robust single spindle, ensuring superior performance.
--For profiles with a maximum diameter of up to 13mm, our premier selections are the B13 and CK1113 models, designed for optimal precision and reliability.
--The CK0620A2 model is an industry leader in processing intricate-shaped parts, including linear, taper, and arc threads. When outfitted with a center frame, it transforms into the ideal solution for slender shaft parts.
--The CK0625A model is expertly engineered for the precision processing of a wide array of components, including instruments, meters, electronic connectors, optics, automotive and motorcycle parts, and small hardware.
--The CK32A3 is a versatile Turning & Milling CNC Lathe, with the CK32A3-B variant offering an enhanced dual spindle configuration based on the refined CK32A3 design.
--The X42 is a slant-bed CNC lathe, meticulously crafted for processing shaft and disc parts that demand exceptional precision and accommodate complex sizes.
--For further insights and detailed information, please reach out to us, or send us your profile drawings for a professional recommendation tailored exactly to your specifications.
Company Profile
Anhui Yuzhou Machine Tool Co., Ltd. (BYSK Baoyu CNC) Pioneering the future with cutting-edge technology, Anhui Yuzhou Machine Tool Co., Ltd. is a comprehensive high-tech enterprise at the forefront of R&D, production, sales, and services. Our expertise spans CNC systems, CNC machine tools, automated production lines, industrial robots, the Internet of Things, and beyond. Originally established as Zhejiang Baoyu CNC Machine Tool Co., Ltd., we boast a manufacturing base of 35,000 square meters in Taizhou, Zhejiang, and an advanced R&D center in Hangzhou, known as Hangzhou AOGE CNC Technology Co., Ltd. In 2013, Anhui Yuzhou Machine Tool Co., Ltd. was set up in Guangde, Anhui, expanding over a vast area of 100,000 square meters.
Our company is renowned for producing a wide array of high-precision equipment, including CNC SWISS-type/Sliding Headstock Lathes, High-Precision Gang-type CNC Lathes, Turning & Milling Compound Centers, Flat Bed CNC Lathe Machines, Slant-Bed CNC Lathes, Horizontal CNC Lathes, Vertical CNC Lathes, Single Spindle CNC Machinery, and Automatic Double-Spindle Lathes. Our lathes are meticulously designed with state-of-the-art absolute value servo and bus connection systems. Our company
proudly holds
an impressive portfolio of over 10 invention patents, utility models, and design patents. Our innovative products
are
extensively utilized in diverse industries including communication equipment, connectors, 5G technology, mobile phones, household devices, defense, aerospace, medical instruments, automotive, water heating systems, miniature shafts, optical instruments, watches, eyewear, and a variety of hardware accessories. Our competitively priced products are the perfect solution for automated batch production across all sectors.
With a commitment to excellence, we implement modern management philosophies and continuously refine our manufacturing processes and services. We are proud to have achieved certifications such as ISO9001 (2016 Quality Management System), ISO14001 (2016 Environmental Management System) , Measurement Management System Certificate, and the Good Standardization Certificate. Our products have also attained the CE Certificate and other prestigious certifications.
As an independent production powerhouse, we are dedicated to enhancing the value of each product, steadfast in our mission to deliver top-tier products and unparalleled services, maximizing value for our customers.We uphold the business principles of
service, innovation, specialization, and pragmatism,
driving us towards our vision to
become the leading provider of the most cost-effective machine tools worldwide.
FAQ
1. Do you accept OEM/ODM?
Reply: Yes. OEM/ODM are welcomed.
2. How many years of production experience does your company have?
R: Over 10 years. We have a team of professional and seasoned technical instructors to provide you with comprehensive after-sales guidance.
3. Is it possible to deliver quickly (or how many days is the delivery guaranteed, the delivery deadline)?
R: Yes, under normal conditions, our lead time is approximately 30-45 working days.
4. What are the after-sales services?
R: We offer a professional technical team available 24/7 to resolve any issues you may have.
5. Does this product accept customized services? What specific aspects can be customized? (Such as color, shape, size, etc.;)
R: Yes, customized services are available. We can customize various aspects including printing your company's logo.
6. Do you accept small quantity orders (or what is the minimum order quantity, etc.)?
R: Yes, even a single set machine order is acceptable.
7. What are the characteristics of the material of this product?
R: The product is constructed from high-quality gray cast iron and comes with a CE Certificate.
8. What are the unique functions and features of this product?
R: Comparable to European quality Swiss type CNC lathe machines, this product is highly cost-effective, has obtained multiple domestic certifications in China, and boasts superior performance.As an independent production enterprise,we have our own technical research team.
9. What are the application areas or uses of this product?
R: Widely applied in Communication Equipment, Connectors, 5G Products, Mobile Phones, Household Applications, War Industry, Spaceflight, Medical Devices, Automotive, Water Heating, Miniature Shaft, Optical Instruments, Timepieces, Glasses, and various hardware accessories.
10. Is it in stock? Can it be wholesaled?
R: Some models are in stock. Please confirm specific availability with us.
11. Are there any second-hand products for sale?
R: No, sorry.
12. What CNC system do you use?
R: Our CNC operating system is the BYSK190, our company's proprietary brand, renowned in the market for its user-friendly interface and comprehensive functions. Additionally, the LNC system is also available as an option.
13. Are you a factory? Where is your factory located? How can I visit?
R: Yes, we are a factory. Our company is located at Jianshe Road No.1, Economical District, Guangde, Xuancheng City, Anhui Province. You are warmly welcomed to visit us.

---
