EPS Raw Material Foaming Machine for EPS Light Weight Brick Production Line

Product Description

eps raw material foaming machine for eps light weight brick production line
Product Description
HS-CP Series EPS continuous pre-expander machine main features:
The inside layer of the barrel is made of stainless steel, and with heat insulation; The buttons and valves are in one control box, easy operation; With 1st and 2ed expansion devices, the required density can be achieved; The machine includes main body, feeding device, bed dryer and blower; HS-CP Series EPS continuous pre-expander machine technical data:

item		unit	HS-CP-700	JC-CP-900	JC-CP-1100
Barrel	diameter	mm	φ700	φ900	φ1100
	Height	mm	1650	2150	2150
	Volume	Kg/m3	0.6	1.5	2
Steam	Inlet	mm	φ25	φ25	φ40
	pressure	MPa	0.4-0.8	0.4-0.8	0.4-0.8
Compressed air	inlet	mm	φ20	φ20	φ40
	pressure	MPa	0.4-0.8	0.4-0.8	0.4-0.8
Density	1st expansion	g/l	12-30	12-30	12-30
	2ed expansion	g/l	8-13	8-13	8-13
Capacity	15g/l	Kg/h	130	170	250
	18g/l	Kg/h	150	200	280
	20g/l	Kg/h	180	250	320
	30g/l	Kg/h	200	300	380
1st expansion motor		KW	0.55	0.55	0.55
2ed expansion motor		KW	0.25	0.25	0.25
Installation Power		KW	3.8	4.8	4.8
Spindle motor		KW	3	4	4
Overall size (LxWxH)		mm	1850x910x2610	2190x1110x3230	2190x1250 x 3230
Machine weight		Kg	≈750	≈900	≈1100

Detailed Photos
Company Profile
Zhejiang Huasheng Machinery Equipment Co., Ltd, located in Fuyang, Hangzhou City, China, is a manufacturer
for high-end EPS foam machinery and EPS moulds.
Huasheng has developed into a modern and standardized production base with an area of over 18, 000 square meters,
more than 100 employees and a team of highly qualified and educated researchers, and obtained 15 invention patents.
The main products include high-precision automatic pre-expander machine, fully automatic shape molding machine ,
EPS block moulding machine, EPS foam mold, EPS lost foam white area equipment etc.
We warmly welcome all customers and friends from both domestic and abroad.
Certifications
Packaging & Shipping
FAQ
Q: Are you a factory or trading company?
A: We are a factory of EPS machine and EPS mold.
Q: what is your payment term?
A: 30% down payment upon order confirmation, 70% balance payment before shipment.
Q:what is your delivery time?
A: It takes usually 45-60days for machines, and 25-30days for EPS mold.
Q: Do you send engineer to our local place to instruct installation?
A:Yes,if you need,we will arrange engineer for you,and we can provide turn-key job.
Q: Warranty?
A: One year warranty after installation is completed.During warranty period, for broken parts not by man-made and wear parts, factory seller will replace free of charge. the shipping cost will be borne by buyer, seller will equip standard spare wear parts to buyer.

---
