| US$1,800.00-2,500.00 | 1 Piece (MOQ) |
| ITEM | CZ1340G | CZ1440G | |
| Swing over bed | mm | φ330 | φ355 |
| Swing over carriage | mm | φ195 | φ220 |
| Swing over gap | mm | φ476 | φ500 |
| Width of bed-way | mm | 186 | 186 |
| Distance between centers | mm | 1000 | 1000 |
| Taper of spindle | M.T.5 | M.T.5 | |
| Spindle diameter | mm | φ38 | φ38 |
| Step of spindle | 8 | 8 | |
| Range of spindle | rpm | 70~2000 | 70~2000 |
| Head | D1-4 | D1-4 | |
| Metric thread | 23kinds (0.25~11mm) | 23kinds (0.25~11mm) | |
| Inch thread | 40kinds(4~112T.P.I) | 40kinds(4~112T.P.I) | |
| Longitudinal feeds | mm/r | 0.091~2.553 (0.0036"~0.1005") | 0.091~2.553 (0.0036"~0.1005") |
| Cross feeds | mm/r | 0.025~0.69 (0.0012"~0.0345") | 0.025~0.69 (0.0012"~0.0345") |
| Diameter of lead screw | mm | φ22(7/8") | φ22(7/8") |
| Pitch of lead screw | 3mm or 8T.P.I | 3mm or 8T.P.I | |
| Saddle travel | mm | 1000 | 1000 |
| Cross travel | mm | 170 | 170 |
| Compound travel | mm | 74 | 74 |
| Barrel travel | mm | 95 | 95 |
| Barrel diameter | mm | φ32 | φ32 |
| Taper of center | mm | M.T.3 | M.T.3 |
| Motor power | Kw | 1.5(2HP) | 1.5(2HP) |
| Motor for coolant system's power | Kw | 0.04(0.055HP) | 0.04(0.055HP) |
| Machine(L×W×H) | mm | 1920×750×760 | 1920×750×760 |
| Stand (left) (L×W×H) | mm | 440×410×700 | 440×410×700 |
| Stand(right) (L×W×H) | mm | 370×410×700 | 370×410×700 |
| Machine | Kg | 495/555 | 500/560 |
| Stand | Kg | 70/75 | 70/75 |
