AMPAK AP6256 dealer supplies QFN44 2-in-1 WiFi module integrated IC chip
RL78/G12
Renesas MCU
True low power platform for universal applications (63μA/MHz) with 1.8-V to 5.5-V operation,
2 to 16 kbyte code flash memory, 31 DMIPs at 24 MHz
1. Overview
1.1 Function
Ultra-low power consumption technology
VDD=Single supply voltage 1.8 to 5.5 V
Can operate under low pressure
Stop mode
Stop mode
Nap mode
RL78 CPU Core
CISC architecture with three-stage pipeline
Minimum instruction execution time: can be changed
From high speed (0.04167S: @ 24 MHz operation)
High-speed chip oscillator) to ultra-low speed (1S:
@ 1 MHz operation)
Address space: 1 MB
General register: (8-bit registration X 8) x 4 bank
On-chip RAM: 256 B to 2 KB
Code flash
Code flash memory: 2 to 16 KB
Block size: 1 kb
Block erasing and rewriting are prohibited (Safety
Function)
On-chip debugging function
Personal programming (with Flash Shield window function)
Data flash notes
Data flash memory: 2 KB
Background Operation (BGO): Instructions are
Rewrite program memory execution
Data flash memory.
Number of rewrites: 1,000,000 times (typical)
Rewrite voltage: VDD = 1.8 to 5.5 V
High-speed chip oscillator
Select from 24 MHz, 16 MHz, 12 MHz, 8 MHz, 6 MHz
4 MHz, 3 MHz, 2 MHz and 1 MHz
High precision: +/- 1.0% (VDD = 1.8 to 5.5 V, TA = -20
to +85°C)
Operating ambient temperature
TA= -40 to +85°C (A: Consumer Application, D:
Industrial Applications)
TA= -40 to +105°C (G: Industrial Application) Note
Power management and reset functions
Chip motor power supply (POR) circuit
On-chip voltage detector (LVD) (select interrupt and
Reset 12 levels)
DMA (Direct Memory Access) Controller Comments
2 channels
Number of clocks during transmission between 8/16-bit SFR
and internal RAM: 2 clocks
Multiplier and divider/multiplier accumulator
16-bit x 16-bit = 32-bit (not signed or signed)
32 bit x 32 bits = 32 bits (unsigned)
16-bit x 16-bit + 32-bit = 32-bit (unsigned or
sign)
Serial interface
CSI: 1 to 3 channels
UART: 1 to 3 channels
Simplified I2C communication: 0 to 3 channels
I2C communication: 1 channel
Timer
16-bit timer: 4 to 8 channels
12-bit interval timer: 1 channel
Watchdog timer: 1 channel (can be used with
Special low-speed film
Oscillator)
A/D converter
8/10-bit resolution A/D converter (VDD = 1.8 to 5.5 V)
8 to 11 channels, internal reference voltage (1.45 V),
and temperature sensor notes
I/O port
I/O ports: 18 to 26
(n-ch open drain I/O [with 6 V] voltage: 2,
N-CH open drainage I/O [VDD withstand voltage]: 4 to 9)
Can be set to N-CH open drainage, TTL input buffer, then
On-chip pull-up resistor
Different potential interfaces: can be connected to 1.8/2.5/3
V-device
Chip key interrupt function
On-chip clock output/buzzer output controller
Others
On-chip BCD (binary decimal) correction circuit
Note that only select in HS (High Speed Master)
model.
Notes The functionality installed depends on the product.
Please refer to 1.7 Functional Overview.
>>
