CTP Printing Plate Film DOT Testing Device Densitometer

Product Description

EcooGraphix Densitometer for Testing CTP Plate Film Press Dots
Model:EcooPlate
The measurement of the right dot transfer on offset printing plates is a key segment of comprehensive process control in the printing industry. At present, plate measurement technology based on microscopic image capture and processing is the established standard. RePlate unifies all advantages of this modern measurement technology in a compact, hand-held instrument.
Feature
1.Android system, with photo taking, data measuring & saving, wifi connection functions;
2.720P high resolution touch-screen can represent print image dots clearly;
3.Auto-focusing camera can easily realize two different scopes magnifying representation;
4.Advanced image processing technology, ensures the data measurement accuracy;
5.Eight built-in measurement tools can fulfill not only dot percentage and image screening measuring, but also measure length, angle, area, etc.
Main Function:
•Measure Dot Percent
• Measure Screening
•Measure Screening Angle
• Measure Dot Size
•Measure Line Distance Measure Angle
Additional function
•View Press Dot
•Save the picture in SD card
•Connect to PC with USB2.0 Major technologic index

Sensor	CMOS 1280 x 1024
Light source	High degree White light LED x 8
Display	TFT Color
Memory	2GB SD
Communication Port	USB2.0
Max Magnification	100
Repeatability	± 0.5 %
Power Supply	V:3.7V battery capacity:3000mA
Dimensions	126mm x 75mm x 50mm
Weight	200 g

accurate measure of plate, precise measure of prints

---
