Santhai Efficient Hygienic Grade Stainless Steel Automatic Sampling Valve Made in China

Product Description

Sample valve:
Operation: Rotate the hand wheel clockwise to elevate the valve shaft and seal, opening the valve for sampling. Conversely, rotate it anti-clockwise to lower the shaft and seal, thus closing the valve.
Yogurt Sampling Valve:
Safety Feature: The internal valve seat design ensures protection against accidental opening caused by excessive pipe pressure.
User-Friendly: The valve remains normally closed by spring action. Simply push the handle to open and release it to close.
Hygienic Design: Complete drainage capability ensures no residue remains inside the valve.
Feature:
1. High-Quality Materials: Constructed from 304 stainless steel and 316L stainless steel for durability.
2. Leak-Proof Assurance: Equipped with a silicone O-ring and plunger.
3. Sanitary Standards: Polished to meet sanitary surface finish standards.
4. Versatile Application: Ideal for use in wineries.
5. Flexible Connections: Available with clamp, thread, or weld end connections.
Technical specification

Material of Product Wetted	316L (DIN-1.4404)
Material of Non-product Wetted	304 (DIN-1.4301)
Seal material	PTFE/VMQ,PTFE/FPM (PV-1),PTFE (PV-2)
	All seal materials comply with FDA 177.2600.
Continuous working temperature	-10ºC/5F-120ºC/248F
Sterilization temperature	150oC (Max 20min)
Working pressure	10bar 145psl
Internal surface	Ra0.8μm
External surface	Shot blasting
Size	DN6/M4,DN8/M4,DN15/W9

Technical Specification:
Connections: Options include thread, clamp, and weld.
Maximum Pressure: 10bar (145psi).
Minimum Pressure: Suitable for vacuum applications.
Temperature Range: Operates effectively between -10°C and 120°C.
Body Material: Available in AISI304 and AISI316L stainless steel.
Seal Material: Made from PTFE (compliant with FDA 177.2600).
Available Sizes: 1/4'', 3/8'', 1/2'', 3/4''.

---
