Environment Friendly Used Tire Recycling Machine / Complete Tire Recycling Plant

Product Description

Environment Friendly Used Tire Recycling Machine / Complete Tire Recycling Plant
Details of waste tyre recycling machine:
The internal cavity of the roll is processed to make temperature well poportioned on the roll surface.and make cooling water cycling treatment,for this products we have applied patent in CHINA.
b,We use the Hardened reducer.
XKP-400/450/560 type waste tire rubber powder production machine
Process flows: waste tires--- circle cutting--- strip cutting--- block cutting--- magnetic separating---rubber powder.
rubber powder processing equipments: The whole set of rubber powder making equipments are consist of three main parts: scrap tires separating equipments, crusher set and grading magnetic separator.
Whole line showing:
The list of machines:
No Name model quantity Power
whole tire pre-processing , you will get < 50*50MMrubber crumb
1 Ring cutter QQJ-1200 1 5.5KW
2 Loop machine YQJ-295 1 15KW
3 Strip cutter QTJ-370 1 5.5 KW .
4 Block cutter QKJ-200 1 11 KW
Rubber powder processing: you will get 20-30 mesh rubber powder,at the same time,
separate the fiber and steel wire
5 Tyre crusher XK560 1 75 KW
6 Big conveyor equipment BCL-8 1 2 KW .
7 Small conveyor equipment BCL-3 1 1.1 KW
8 Big Magnet separator BMS22 1 2.2 KW
9 Small Magnet separator SMS-1 1 1.1 KW
10 Big Shaking screen BSS-8 1 7.5 KW
11 Small Shaking screen SSS-3 1 3 KW
Total amount (FOB Qingdao) 11 sets 128.9KW
To load all above machines, we need one 40" top open container and one 20" GP container.
Final product:
Diferent size of rubber powder
Different uses of final rubber powder:
Guaranetee & after sales service:
1.One year guarantee for whole machine
2.24hours technical support by email or other tools
3.Calling or door -to -door service
4.Use friendly english software user manual and detailed videos.

If you are interested in our machines,or have any qusstions,contact us freely~

	XKP-400	XKP-450	XKP-560
Working diameter of front roller(mm)	Φ400	Φ450	Φ560
Working diameter of rear roller(mm)	Φ400	Φ450	Φ510
Working length of rollers(mm)	600	760	800
Serface speed of front roller(m/min)	20	23.2	25.56
Velocity ratio of rollers	1:1.38	1:1.38	1:1.3
Maximum gap between rollers(mm)	8	8	8
Capacity(kg/h)	300	400	500
Power(kw)	45	55	75
Dimension(mm)	3950*1800*1780	4770*1845*1835	5064*2284*1978
Weight(kg)	7000	12000	19000

---
