Computerized Electronic High Speed Industrial Pattern Zigzag Sewing Machine

Product Description

HL-2290A Computerized Electronic High Speed Industrial Pattern Zigzag Sewing Machine
HL-2290A Computerized Electronic High Speed Industrial Pattern Zigzag Sewing Machine

Model Name	HL-2290A
Application	Light/medium/heavy
Max. sewing speed	5000 spm
Lift of presser foot	5.5-10mm
Stitch Length	5mm
Needle type	DP*5 10-14#
Weight of machine head	45/40kgs
Carton CBM	660*340*730MM

FEATURES:
1. Outer switching-button design, makes the switch between 2-step and 4-tep zigzag very easy & convenient.
2. Outer switching- late design, makes the adjustments amongst 2mm, mm., 8mm., 10mm so easy and quick.
3. Adopting Japan-made HIROSE highest quality Titanium Hook, ensures smooth stitches & durability. Also China-made hook is optional.
4. With the improved needle-position-shifting-lever, fine adjustments of needle position much more simplified. Moreover, needle position can be fixed firmly by the new design of a stopper provided on the lever.
5. New design of rotary thread take-up lever ensures uniform thread tension at no matter high or low tension stitching.
6. Offcenter axis hook mechanism has been adopted eliminating problems of jumping stitches and thread breakage.
7. Hemmer & folder are optional.
8. Fully improved built in type bobbin winder makes it easier to adjust the amount of thread to be wound in bobbin and thread tension when winding bobbin.
9. Elastic feeding device for zigzag sewing machine, special for sewing high quality ladies'& gentlemen's underwear.(optional)
10. Screw pump type fully automatic lubrication system ensures stable flow of oil to the hook under pressure at all speeds.
11. The new presser bar pressure regulating knob enables the simple adjustment of presser bar pressure.
12. Standard zig zag exceeding zig zag width of 6mm of more and 3-step zig zag
exceeding bight width of 8mm or more conform to Table.
APPLICATIONS:
1. Attaching laces, shoulder straps, and general zigzag stitching.
2. Attaching elastic tapes or laces to leg or waist portion of tights, swim suits etc..
3. Attaching elastic tapes or laces to corsets, bras, ladies' underwear etc.. Also can work for decorative purpose sewing.
4. General or decorative sewing for tights, pajamas, negligee, ladies' & children's ware etc...
The machine is designed as electronical and machine integration, it has automatic stop, dial thread, trimmer,reserve and clockwise seam etc, series automatic function, improve production efficiency.The machine has simple changover lever,it can use for standard zigzag and 3-step zigzag,so it improves the efficiency,without changing another sewing machine, it is provided with adjustable height of the feed dog device to avoid aberrancy when seaming elastic fabric. It adopt not rotarying bobbin,it will not occur bobbin empty racing seam fault,it can maintain the bobbin thread tension.This machine is applicable for seaming underwear,swimsuit etc.
New type rotary thread take-up ensures uniform thread tensions under low-tension settings. Axis hook acting in concert with compensation has been adopted, and the hook points to catch thread loop at equivalence to left and right, thereby reducing skip stitching and thread breakage considerably. It's equipped with mini-lifter-and-presser foot which makes the presser foot up, and then sewing the flexible cloth with nice looking and soft stitches. Winder is designed in particular so that the machine can be used with more convenience. 2284N can achieve sewing directly,2-step zigzag, 4- step zigzag and 11 patterns zigzag with changing cam which increases the production efficiency.

HIGHLY brand sewing machine company is a reliable leading manufacturer and distributor for all kinds of sewing machines. The products scope include basic industrial sewing machine, such as single & double needle lockstitch sewing machine, heavy duty sewing machine, overlock sewing machine, interlock sewing machine, multi needle sewing machine, button attaching and button holing sewing machine, bar tacking sewing machine, zigzag sewing machine, handstitch sewing machine, chainstitch and blindstitch sewing machine, household sewing machine and cutting equipments. Also includes some special type and high precision technology sewing machine, such as leather sewing machine, shoes sewing machine, sofa sewing machine, jumbo & woven bag sewing machine, suitcase & handbag sewing machine, sail & tent sewing machine, labor & rope net sewing machine, seat & cushion sewing machine, programmable pattern sewing machine, mattress sewing machine, embroidery sewing machine, carpet overedging sewing machine, and so on.
We are very especially professional on super heavy thick material sewing machines and long arm sewing machines. Our sewing machines are widely used in clothes, shoes, sofa, jumbo bag, woven bag, suitcase, handbag, carpets, tent, umbrellas, luggage, leather and knitting industry. The reliable quality and good after sale service gained a positive comments and reputation from our customers. The sales network has covered more than 80 countries and regions in the world, such as South & North America, Europe, Middle East, Asia, Africa, etc. The Company has obtained in succession the certification of ISO9000, SGS, and CE certificates.
With the principle of "Highly products, Highly quality, Highly service", we would like to continue researching more advanced and functional garments machinery for different markets and requirements, so that we develop stable business cooperation with all clients from all over the world on the base of mutual benefit. "Highly Products, Highly Quality, Highly Service", you choose, you believe. You are always welcome to cooperate with HIGHLY brand sewing machine company, including OEM cooperation with your brand. You are warmly welcome to be our agency with our registered brands Highly, PARADA, WELMAC, Mastman.

---
