Heavy Process CNC Machine Lathe From China Taiwan CNC Lathe with X/Z/C and 12/12 Power Tool Turret with Live Tooling

Product Description

DAS TS-8/10DII Large Travel Dual Spindle Dual-Channel CNC Lathe with Dual Power Turret Product Description
1.Power tool with single drive mechanism can be mounted in all positions Maximum torque of 25N m for heavy-duty cutting Increased number of tools, 2nd turret that can be equipped with.
2.The number of tool mounting faces has been increased to 8 from 6 on previous models. In addition, a double plane tool mounted,allowing a significant increase in the number of tools to be mounted, In addition,up to 4 powerhead tool holders can be installed.
3.The 1st turret and 2nd turret can machine both the 1st spindle and 2nd spindle simultaneously, allowing for higher machining efficiency.
4.By overlapping control of the 2nd spindle movement command,which can move in the X/Z direction,with the lst turret's axis movement command, machining time can be significantly reduced.

Model	TS-8-DII
Max.swing diameter(mm)	550
Max.cutting length(mm)	600
Max turning diameter(mm)	300
Spindle nose	A2-6
Spindle speed(r/min)	0-2500
Spindle power(kw)	11
Tool installation	BMT65
Max.number of tools(pcs)	12
X1/Z1 axis travel(mm)	500/580
X2/Z2 axis travel(mm)	500/580
X1/Z1 axis servo motor power	3.9/3.9
X2/Z2 axis servo motor power	3.9/3.9
Guide form	Linear guide way
X/Z axis axis fast moving speed(m/min)	20/20
Hydraulic station motor power(kw)	3.75
Pump motor power(w)	750
Spindle bore(mm)	Φ62
Sub-spindle bore(mm)	Φ62
Net Weight(KG)	7200
Machine Power(kw)	44
Machine Dimensions(LxWxH)(mm)	3800*2400*2000

1. Machine tool control system uses Taiwan SYNTEC 6TA-T3S system. Other Brand including GSK,Fanuc,Siemens are OK!
2. Machine body is cast in one piece. The lathe bed tilts by 45°and the inclined placement of lathe carriage.
3.Taiwan's high-precision spindle, comprising Japan NSK precise bearings; three-jaw hydraulic chuck or other elastic clamp can be directly fitted on the main shaft flange.
4.The drive part of machine tool uses HIWIN/PMI high precision P3 class ball bearing screw and high speed linear slide rail.
Good Feedback
Foshan Shunde Guoqiang Daosheng Industrial Co., Ltd. is located in Chencun, the important machinery town in Shunde District,Foshan. Sticking to the human-centering management, we are in possession of a group of highly competent technical personnel, a market oriented experienced sales team. In the gesture of sincere cooperation, we strive to establish a promise keeping and quality .
Our major products include CNC series gang tool type lathes , turret lathes, take heart-type lathes and milling-type lathes, featuring space saving, low cost and diversified arrangement etc.
They can also meet the demand for precise processing of different products. The products find widespread application in the manufacture of cars, motorcycles and accessories thereof,electronic industry, optical instruments, clocks and watches as well as special motors etc.
We have precise lathe equipment, complete quality guarantee system, prompt goods supply as well as perfect after-sales service,which ensure us the first consideration when you purchase high-precision machine tools.

---
