4V210-08 5 way Normally closed solenoid valve pneumatic Control air Valve

Product Details

Product Description

Product Description
4V210-08 5 way Normally closed solenoid valve pneumatic Control air Valve
Order code for 4V210-06/4V210-08
Symbol for 4V210 direct acting solenoid valves
Technical parameter

Model	4V210-M5	4V220-M5	4V230C-M5	4V230E-M5	4V230P-M5		4V210-06	4V220-06	4V230C-06	4V230E-06	4V230P-06
Fluid	Air
Acting	Internal pilot solenoid valve
Valve type	5/2 way		5/3 way			5/2 way			5/3 way
Orifice size	5.5mm2		5mm2			12mm2			9mm2
Lubrication	No required
Port size	In=out=M5						In=out=G1/8''
Protective class	IP65
Pressure range	0.15-0.8MPa(21~1145Psi)
Proof pressure	1.2MPa(170psi)
Material of body	Aluminum Alloy
Temperature	-5℃~60℃
Response speed	<0.05s

Dimension for 4V210 4V310 4V410 external pilot Solenoid valve
Feature
* Airtac Type Air Pneumatic Control Solenoid valve 4V210-08
* Aluminum material Body width 18mm,22mm,27mm,34mm
* Pilot Operated,Inner Pilot type
* Life cycle 10000000 times
* Pipe joint and Namur joint type for option
* Din connector and outlead wire electricity connecting for selectable
* Metal Manual Override ensure stability when power failure or necessary functional motion
* High quality pilot armature ensure rapid and sensitive feedback when connect eletricity
* IP65 class Electromagnetic Induction Coil,low consumption,long service life
* Mature products,cost effectively

---
