Ruihang PP PC Hollow Lattice Board Sunlight Roofing Sheet Extrusion Machine

Product Description

Ruihang PP PC Hollow Lattice Board Extrusion Machine
Production line composition:
Automatic feeder, high-speed mixer, twin-screw extruder, screen changer, mold, vacuum shaping table, traction machine, stress reliever, cutting machine, etc.
Main features of the production line:
The screw and barrel are optimized and processed with high-performance alloy steel. The advanced temperature control system makes the whole machine have the advantages of uniform plasticization, stable extrusion volume, high output and long life.
Mold: The mold is made of high-quality alloy steel with a highly active throttling device, so that the pressure of the raw material flow in the die is uniform and consistent. The upper and lower dies are differentially adjusted to ensure the uniform thickness of the upper and lower walls.
A fast heat exchange refrigeration system is provided in the shaping system. It is effectively interlaced with the vacuum system, and the suction distribution is uniform and reasonable. This distribution ensures the shaping accuracy. The vacuum system consists of two independent subsystems. Each subsystem is equipped with multiple three-point fixed cycle vacuum groups, and each fixed cycle carries a vacuum adjustment system and a vacuum display system to make the vacuum degree on the surface of the plate uniform and stable.
The advanced large-area conduction heating method effectively eliminates the stress of the plate and further improves the flatness of the plate.
Equipped with instant fixed-length cutting and automatic lifting and unloading devices, special alloy wear-resistant blades to ensure the quality of the cut surface of the plate. Plates thicker than 5mm are cut with saws.
Features and applications of the products produced
1. Good mechanical properties
2. Light weight and material saving
3. Heat insulation and sound insulation
4. Anti-static, conductive, flame retardant
5. Stable chemical properties
6. Smooth and beautiful surface, complete colors
7. Obvious environmental protection effect Plastic hollow board has the characteristics of non-toxicity and pollution-free, simple waste treatment, and will not pollute the environment. It can also be recycled to make other plastic products.
Application areas: electronics, automobiles, machinery, logistics, glass, advertising, food, medicine and other industries.
Main technical parameters:

Raw Material	PP	PP	PC	PC
Extruder Specifications	SJ-100/36	SJ-120/36-SJ150/36	SJ-120/36 SJ-45/30	SJ-100/36 SJ-45/30
Main Motor Power(kw)	75	110-132	185/22	132/18.5
Product Width(mm)	1300-1600	1600-2600	1600-2100	1300-1600
Product Thickness(mm)	2-10	2-10	2-25	2-20

Detailed Photos:
Products Photos:

---
