Portable Light Duty Small 1400 Lbs Hand Winch

Product Description

Product Description
Crank Manual Dual Gear Hand Winch with brake is a high quality multi-purpose winch used for a wide variety of lifting and hoisting applications. The automatic brake ensures the load remains suspended when the crank is released and avoids unchecked descent of the load; there is no freewheeling making the hand winch extremely safe to operate. All the mechanical components are enclosed for protection against dust, dirt and rain contamination. This equipment has a lifting capacity ranging from 800lbs to 2600lbs.
Product Feature:
•High quality multi-purpose winch •Gears and brakes fully covered to prevent dust, dirt and rain contamination •Universal mounting plate •Automatic load-actuated brake can hold the load in any position •Heat treated gears •Available as 800lb, 1200lb, 1800lb, and 2600lb models,etc. •Very low operator effort required for easy operation •For cable and strap •Operating temperature of -20°C to +80°C (temperature range of -40°C to +80°C available as an option)

Model Rated capacity (LBS) Test load(kn) Single speed / double speed Transmission ratio Hand operated strength(N)		600LBS	800LBS	1000LBS	1200LBS	1400LBS	2000LBS	2500LBS
		600	800	1000	1200	1400	2000	2500
		4.1	5.4	6.8	8.2	9.5	13.6	17
		Single	Single	Single	Single	Single	Double	Double
		2.9:1	3.7:1	4.2:1	4.2:1	4.2:1	10.35:1	11.5:1
							4.5:1	5:1
		70	75	85	100	120	150	160
Dimensions (mm)	A	φ21	φ21	φ21	φ21	φ21	φ27	φ27
	B	φ116	φ116	φ135	φ135	φ135	φ150	φ165
	C	51	51	51	51	51	65	65
	D	119	119	119	119	119	174	174
	E	φ25	φ25	φ25	φ25	φ25	φ25	φ25
	F	228	228	228	228	228	281	281
	G	91	91	91	91	91	91	91
	H	138	138	156	156	156	182	191
	J	165	165	184	184	184	250	256
	R	180	180	180	180	180	251	251
Net weight(no wire rope) kg		2.4	2.5	2.8	2.8	2.8	5.9	6.4

Can I get a sample before order? sure, we provide you Free sample within 3-5 working days.
Ccan you accept small order? for some normal items, we can do small quantity according your details requirement.
How about your delivery time? 25-30days

---
