Wheat Seed Separator 5xw Rice Paddy Ryegrass Cumin Oats Grader Rape Socket Length Indented Cylinder

Product Description

HAIDE APM Wheat Seed Separator China Manufacturing 5XW Rice Paddy Length Indented Cylinder Grader Machine

Product Description
Introduction and Function
5XW Seed Indented Cylinders are used for sorting and separating granular and free-flowing products such as wheat, paddy, barley, maize, fine seeds, and sticks from sunflower or sugar beet, plastic particles, etc.

5XW Indented cylinder machine is equipped with one indented cylinder for short grain separation and one for long grain separation (for series mode). Two Cylinders can also be used for both long and short impurity separation, removing only one impurity and doubling the yield (Used in parallel). Inside each cylinder, there is a trough with an auger conveyor. Each cylinder is driven by a gear motor.
Detailed Photos
Product Parameters

Item		Unit	Specification
Overall Dimension (LxWxH)		mm	3881×1040×2330
Total Weight		kg	1500
Rated Capacity		t/h	5
Power	Motor		Cylinder Motor×2
	Type		YSJ90L4
	Power	kW	1.5×2
	Rotate Speed	rpm	1400
Cylinder ×2	Dimension (Dia.×L)	mm	Φ700×2700	Φ700×2700
	Indented Pocket Diameter	mm	5.6 or 8.5	5.6 or 8.5
	Rotating Speed	rpm	38~48(adjustable)	38~48(adjustable)
	Dip Angle	(°)	0	0
Product Trough Adjustable Range		(°)	0~360	0~360

Notes:
1. The machine can be converted to different cleaning programs, cylinder cover shall be changed accordingly.
2. Above technical data can vary due to continued development, or different machine configurations.
Advantages
1. Gentle processing of the product
2. High standard of separating quality by asymmetric pocket cells

3. Segmented cell cylinder makes for a simple and quick changing of the cylinder casings

4. Easy and adjustable trough positioning

5. Free of vibration and operation smooth
6. Bolted housing made of painted sheet steel

7. Individual drive unit for each indented cylinder gear motor

8. Indented cylinder completely covered for operator safety

9. Aspiration connection for further dust cleaning

10. low voice
Product Details
