| Distance | Visible light Camera | 2000m-3000m |
| Thermal Camera | Target | Human(1.8m×0.5m) | Vehicle (2.3m×2.3m) |
| Detection | 5040m | 14400m |
| Recognition | 1260m | 3600m |
| Identification | 630m | 1800m |
| Fire Alarm Distance | 1m*1m | 2m*2m |
| 3600m | 7200m |
Visible light camera
| Sensor | 1/2.8" Progressive Scan CMOS |
| Valid pixel | 2.1MP |
| TV Line | 1920*1080 |
| Focal length | f=7.9-316mmmm,40x optical zoom |
| Iris | F1.8-F6.0 |
| Optical permeable fog | Support |
| Optical Stabilizer | Support |
| Electronic shutter speed | Auto/Manual |
| Lowest illumination | 0.05Lux(color );0.01Lux (black&white ) |
| Camera control | support manual switch day&night mode, backlight compensation, auto white balance, auto gain control |
| Auto focus | Supporting |
| Format | H.264 |
| Frate | 1~30frate/s |
| Caption overlay | Logo,date,time |
| Image adjustment | Brightness,contrast,saturation |
| Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP,RTSP,PPPoE,SMTP,NTP,UPnP,SNMP,FTP,802.1x,QoS,HTTPS,IPv6 (SIP,SRTP,optional) |
| Thermal camera | Detector Type | Uncooled microbolometer Focal array detector, VOx |
| Pixel | 640×512 |
| Spectrum Range | 8~14μm |
| NETD | ≤50mK@F1.0, 300K |
| Focal lenth | 36~180mm |
| FOV | 3.5°×2.8°~17.2°×13.6° |
| IFOV | 0.47~0.09mrad |
| Lens control | Electronic zoom/focus, auto focus |
| Image process | DDE, 10 Pseudo Color |
| Pantilt | Load | 50kg (top mounted) |
| Pan angle | 360°, continuous rotation |
| Tilt angle | -45°~+45° |
| Pan speed | 0.01°~ 12°/s |
| Tilt speed | 0.01°~8°/s |
| Preset | 255 |
| Preset precision | ±0.1° |
| Auto cruise | 2 path, 64 presets each path |
| Auto line scan | 1 path |
| Communication protocol | Pelco-D,Pelco-P optional |
| Bit rate | 2400/4800/9600/19200 bps optional |
| Anti-lightning | Power supply 4000V, video signal 2000V |
| Interface | Power | DC30V |
| Internet | 1×10Base-T/100Base-TX, RJ45 interface |
| Environment | Operation temperature | -25ºC~+55ºC |
| Storage temperature | -40ºC~+65ºC |
| International protection | IP66 |
| Salt fog proof | PH6.5~7.2, Continuously spraying 48 hours |
| Power | Whole power supply | DC30V±1.0%, accompanied with 220VAC~30VDC wide range power adapter |
| Power consumption | ≤100W |
| Physics | Weight | ≤45kg |
| Installation | Outdoor base installation |
